Description
Bently Nevada 330380-90-00: Heavy-Duty High-Temperature Proximitor Sensor for Critical Monitoring
Overview
Panel-mount sensor engineered for extreme environments. Handles -51°C to +100°C operation with 100% humidity tolerance. Aluminum housing with epoxy coating for corrosion resistance.
Technical Specifications
| Manufacturer | Bently Nevada |
| Complete Model | 330380-90-00 |
| Configuration Details | |
| – Total Length | 90 = 9.0m (29.5 ft) |
| – Mounting Type | Panel Mount |
| – Hardware Kit | 00 = Not included |
| Power Requirements | -19.6 to -26 VDC (12mA max) |
| Output Resistance | 50 Ω |
| Voltage Sensitivity | <13mV/V change |
| Housing Material | Epoxy-coated aluminum |
| Weight | 0.255 kg (9 oz) |
Environmental Ratings
- Operating Temp: -51°C to +100°C
- Storage Temp: -52°C to +105°C
- 100% condensing humidity tolerance
- Submersible when connectors sealed
Installation Features
- Direct panel mounting – no brackets needed
- Maintain 15cm clearance from heat sources
- Use 24VDC regulated power supply
- Ground shield at monitoring system end
Packaging Contents
- 1x Proximitor sensor (330380-90-00)
- Made in USA certification
Warranty & Delivery
12-month performance warranty. Ships via FedEx/DHL/UPS in 24-48hrs.
Technical FAQ
Q: Minimum voltage requirement?
A: -19.6 VDC absolute minimum for operation
Q: Cable armor options?
A: Standard unarmored – armored versions require custom order
Q: Calibration needed?
A: Factory pre-calibrated – field verification recommended
Q: Hazardous area certification?
A> ATEX/IECEx versions available under different model suffix
