Bently Nevada 330701-00-15-50-01-CN 3300 XL 11 mm Proximity Probes

Description

Bently Nevada 330701-00-15-50-01-CN Industrial Vibration Guardian

Core Technical Advantages

5-Meter Deep Signal Integrity | Country-Specific Certifications | 1.5in Compact Profile

Precision Engineering Breakdown

• Cable Resistance: 5.9Ω ±0.5 (1m baseline)
• Thread Torque: 15.2N·m operational / 45.2N·m max
• Bend Radius: 25.4mm minimum curvature
• Seal Endurance: Viton® O-ring (-34°C low temp limit)
• EMI Protection: Triaxial shielding @ 75Ω

Full Suffix Architecture

330701-00-15-50-01-CN
├── 00: Zero unthreaded length (flush mount)
├── 15: 38.1mm (1.5") case length
├── 50: 5m FEP-insulated cable
├── 01: ClickLoc connector + standard cable
└── CN: Local regulatory compliance

Installation Masterclass

• Optimal thread engagement: 19mm maximum
• Clockwise connector rotation for secure ClickLoc lock
• Thermal expansion gap: 0.5mm minimum at -30°C

Expert Insights Q&A

Q: Can the 5m cable be used with non-Bently monitors?
A: Requires 75Ω impedance matching – consult interface manuals

Q: Acceptable for food production areas?
A: Yes – 304 SST and FEP meet FDA 21 CFR 177.1550

Q: Maximum vertical cable run?
A: 30m elevation supported with proper strain relief
