Description
Compact Vibration Sensor with Short Cable
The Bently Nevada 3300 XL 11 mm Proximity Probe is perfect for tight spaces. It has a short 1-meter cable and a compact 2-inch case. This model uses a larger 5/8-18 thread for secure mounting. It provides precise vibration data close to your monitoring system.
Main Advantages
- Space-Saving Design: Short case and cable for confined areas.
- Robust Mounting: 5/8-18 UNF thread offers strong hold.
- Fluid-Resistant: FluidLoc cable protects against wet conditions.
- Wide Temperature Range: Works from -51°C to +177°C.
- Easy Connection: ClickLoc connector for quick hookup.
Product Configuration: 330707-00-20-10-12-00
- Base Product Identifier
- 330707 – 3300 XL 11mm Probe, 5/8-18 Thread, Unarmored
- Detailed Option Selection
- -00 – Unthreaded Shank: 0.0 inch
- -20 – Probe Case Length: 2.0 inches
- -10 – Total Cable Length: 1.0 meter
- -12 – Cable/Connector: FluidLoc with ClickLoc
- -00 – Safety Approvals: Not specified for this order
Technical Specifications
- Product Details
- Manufacturer: Bently Nevada
- Model Number: 330707-00-20-10-12-00
- Product Family: 3300 XL Vibration Sensors
- Electrical Characteristics
- DC Resistance (1m): 5.9 ± 0.5 Ohms
- Cable Construction: 75 Ohm Triaxial, FEP FluidLoc
- Physical Construction
- Case Material: AISI 304 Stainless Steel
- Tip Material: Polyphenylene Sulfide (PPS)
- Mounting Thread: 5/8-18 UNF
- Max Thread Engagement: 0.938 inches
- Installation Data
- Install Torque: 15.2 N•m (133 in-lbs)
- Max Torque: 45.2 N•m (400 in-lbs)
- Connector Torque: Hand tight only
- Min Cable Bend: 25.4 mm radius
- Environmental Ratings
- Operating Temp: -51°C to +177°C
- Low Temp Warning: Seal may fail below -34°C
- Hazardous Area (Ga/Gc): Compliant with T1-T5
- Hazardous Area (Dc): Compliant with T280°C to T90°C
Packaging & Service
- What’s in the Box:
- 1 x Probe 330707-00-20-10-12-00
- Instruction sheet
- Warranty Coverage: Full 12-month manufacturer’s warranty.
- Shipping Methods: We ship globally via FedEx, UPS, and DHL.
- Product Weight: 0.17 kg per unit.
FAQ & Selection Advice
When should I use a 1-meter cable instead of a longer one?
Use a 1-meter cable when your monitor is very close to the measurement point. It reduces cable clutter and cost.
What does the “2.0 inch” case length affect?
It is the physical length of the metal probe body. A shorter case fits where there is limited clearance behind the mounting surface.
Is the FluidLoc cable flexible in cold temperatures?
The FEP insulation stays flexible at low temperatures. However, avoid sharp bends below -34°C to protect the internal seal.
Can I connect this to a monitor with a different connector?
No, it has a fixed ClickLoc connector. You may need an adapter cable to connect to other system types.
How do I pick the right probe length and cable?
First, measure your available mounting depth for the case length. Then, measure the distance to your monitor for the cable length.
Need help configuring a sensor for your application? Message our engineers on WhatsApp: +86 158 8020 0923. View all our 11 mm Proximity Probes online.
