Description
Armored 5m Probe for Matched System Installations
This Bently Nevada 3300 XL 11 mm Proximity Probe is engineered for durability. It pairs a 5-meter armored cable with a compact 2-inch case. Designed specifically for use with 5-meter Proximitor sensors, it ensures signal integrity in demanding environments.
Primary Benefits
- Matched System Performance: 5m cable pairs with 5m Proximitor sensor.
- Maximum Cable Protection: Stainless steel armor resists crush and abrasion.
- Compact Profile: Short 2.0-inch case for space-limited installations.
- Enhanced Durability: Connector protector safeguards the connection point.
- Reliable in Harsh Conditions: Wide temperature range and fluid-resistant cable.
Detailed Product Build: 330707-00-20-50-11-00
- Core Product Designation
- 330707 – 11mm Probe with Armored Cable
- Pre-Configured Options
- Segment 1-2: 00 – Unthreaded Section: 0.0 in
- Segment 3-4: 20 – Body Length: 2.0 in
- Segment 5-6: 50 – Total Cable: 5.0 meters
- Segment 7-8: 11 – Connector: ClickLoc with Protector, FluidLoc
- Segment 9-10: 00 – Agency Certs: Not Required
Complete Specifications
- Product Identification
- Brand: Bently Nevada
- Full Model: 330707-00-20-50-11-00
- Product Line: 3300 XL Monitoring Probes
- Electrical Properties
- DC Resistance (5m): 7.2 ± 0.8 Ohms
- Cable Specification: 75 Ω Triaxial, FEP FluidLoc with Armor
- Mechanical Build
- Probe Body: AISI 304 Stainless Steel
- Sensing Tip: Polyphenylene Sulfide (PPS)
- Mounting Thread: Standard 1/2-20 UNF
- Max Thread Depth: 0.750 inches
- Installation Guidelines
- Optimal Torque: 15.2 N•m (133 in-lb)
- Torque Limit: Do not exceed 45.2 N•m
- Connector Handling: Finger tighten only
- Cable Bend Radius: Minimum 25.4 mm
- Environmental Specifications
- Temperature Range: -51°C to +177°C Operating & Storage
- Low-Temp Advisory: Seal life may shorten below -34°C
- Pressure Seal: Viton O-ring (custom testing available)
Ordering & Support Details
- Package Includes:
- 1 x Armored Probe 330707-00-20-50-11-00
- ClickLoc connector with protective cover
- Our Guarantee: This product is covered by a 12-month warranty.
- Global Logistics: We ship promptly via FedEx, UPS, and DHL worldwide.
Pro Advice & Common Questions
Why must this 5m probe be used with a 5m Proximitor?
System calibration and signal performance are optimized for matched cable lengths. Using mismatched lengths can cause measurement errors.
What is the advantage of the connector protector?
It shields the electrical connector from physical impact, dust, and moisture during handling and installation, preventing damage.
Can I cut the armored cable to a shorter length?
No. The armored cable is a sealed, factory-assembled unit. Cutting it will destroy the probe’s integrity and void the warranty.
Is this probe suitable for outdoor installations?
Yes. The stainless steel armor and FluidLoc cable provide excellent protection against weather, UV exposure, and mechanical damage.
How do I ensure a proper pressure seal in my application?
For standard use, the Viton O-ring is sufficient. If your application involves specific pressure cycles, contact us for custom pressure testing before shipment.
Ensure optimal system performance. This 330707-00-20-50-11-00 is designed for matched installations. For other needs, see our full range of 11 mm Proximity Probes.
