Bently Nevada 330901-00-45-10-02-00 | 3300 NSv Proximity Probe with ClickLoc Connector

Description

Industrial Precision Vibration Probe

This Bently Nevada 3300 NSv Proximity Probe is a high-performance sensor. It measures shaft vibration and position with accuracy. Its robust build ensures reliability in critical machinery monitoring.

Core Product Advantages

• Superior Temperature Tolerance: Operates from -52°C to +177°C. Handles extreme thermal cycles.
• Premium Construction: AISI304 stainless steel case and PPS tip. Resists wear and corrosion.
• Quick-Connect Design: Miniature ClickLoc connector enables fast, secure installation.
• Hazardous Area Certified: Complies with EPL Ga, Gc, Dc standards for safe operation.
• Direct OEM Replacement: Guaranteed compatibility with Bently Nevada 3300 NSv monitoring systems.

Part Number Configuration

Product Identifier: 330901-00-45-10-02-00

• ▸ 330901 – Core Probe (1/4-28 UNF, Unarmored)
  • │ ▸ 00 – Unthreaded Length
    • Specification: 0.0 in
  • │ ▸ 45 – Casing Length
    • Dimension: 4.5 in
  • │ ▸ 10 – Integrated Cable
    • Length: 1.0 m (39 in)
  • │ ▸ 02 – Connection Interface
    • Type: ClickLoc Coaxial Connector
  • └ ▸ 00 – Certifications
    • Status: Standard (No Special Approvals)

Essential Specifications

• Electrical Characteristics:
  • Nominal Resistance (1m cable): 4.2 Ω ± 0.5 Ω
  • Cable Specification: 75 Ω coaxial, FEP insulation
• Mechanical Properties:
  • Thread Type: 1/4-28 UNF
  • Max Thread Engagement: 0.563 in
  • Installation Torque: 11.3 N·m (100 in-lb) recommended
  • Pressure Seal: Viton O-ring
  • Approx. Weight: 14–150 g
• Operating Envelope:
  • Full Range: -52°C to +177°C (Op & Storage)
  • Critical Note: Prolonged exposure below -34°C risks seal integrity.
  • Safety Ratings: EPL Ga/Gc/Dc (T1-T5, T280°C-T90°C)

Quick Start Guide

Mount the probe using the 1/4-28 UNF thread. Respect the 0.563 inch engagement limit. Apply 100 in-lb torque for optimal sealing. Snap the ClickLoc connector into the monitor interface. Need help? Contact our engineers at +86 158 8020 0923.

Package & Support Details

• One (1) 330901-00-45-10-02-00 probe assembly.
• Factory-integrated 1-meter cable with connector.

Global Logistics: We ship via FedEx, UPS, and DHL for reliable delivery.
Customer Assurance: This product is covered by a comprehensive 12-month warranty.

Expert Questions & Answers

What does “without armor” mean for installation?

It indicates the cable lacks a protective metal braid. This makes the probe more flexible for tight spaces within control panels, but requires careful routing away from sharp edges.

Can I use this probe in a high-pressure environment?

The probe is designed to seal differential pressure between its tip and case via a Viton O-ring. It is not rated for full submersion or external pressure containment. Always check system specifications.

How do I claim the 12-month warranty?

Retain your purchase invoice. If a defect appears within one year, contact us with your order number and a description of the issue. We will guide you through the return or replacement via secure courier (FedEx/UPS).

What is the difference between 3300 NSv and 3300 XL probes?

They are for different electronic monitoring systems. The 3300 NSv Proximity Probes connect to NSv series monitors, while XL probes connect to older 3300 XL frames. They are not interchangeable.

What is a common calibration pitfall?

Neglecting to measure the probe’s DC resistance (RPROBE) before installation. For this 1m 330901-00-45-10-02-00 model, a reading between 3.7Ω and 4.7Ω confirms electrical health. Values outside this range suggest damage.
