Bently Nevada 330901-00-90-10-11-00 3300 NSv Probe

Description

330901-00-90-10-11-00 | 3300 NSv Proximity Probe

Premium industrial-grade vibration sensor designed for precision machinery monitoring with 9-inch stainless steel case and 1.0M PPS sensing tip. Features IP67-equivalent protection through Viton O-ring seal rated for -34°C to +204°C.

Key Specifications

• Thread: 1/4-28 UNF (max engagement 9.5mm)
• Weight: 85g ±5g (3oz)
• Cable: 75Ω FEP FluidLoc® (4.8mm OD)
• Connector: ClickLoc® Gold-plated (500+ mating cycles)

Performance Data

• Frequency Response: 5Hz-15kHz (±3dB)
• Shock Survival: 100g peak (11ms duration)
• Insulation: >100MΩ @ 500VDC

Extended Suffix Details for 330901-00-90-10-11-00

• -00: Standard calibration (8mV/μm ±3%)
• -90: 228.6mm case length (L1 dimension)
• -10: 1.0M cable (39.37″)
• -11: MIL-C-38999 connector interface

Certified Compatibility: API 670 compliant, ATEX/IECEx optional (add “-EX” suffix)

Contact Technical Sales:
✉ sales@ubestplc.com

⚠ Installation Note: Requires 5.1N·m torque wrench for proper seating. Exceeding 7.3N·m may damage PPS tip alignment.
