Bently Nevada 330904-00-10-05-01-BR Probe | 3300 NSv M8x1 Armored Sensor

Description

Compact NSv Series Proximity Sensor

Introducing the 3300 NSv Proximity Probe. Model 330904-00-10-05-01-BR is a new, armored sensor. It is perfect for tight spaces and process applications. This probe offers excellent chemical resistance and compatibility.

Part Number Decoder

• 330904 – NSv Probe, M8x1 Thread, With Armor
• -00 Unthreaded Section: 0 mm
• -10 Case Length: 100 mm
• -05 Cable Length: 0.5 meter (20 in)
• -01 Connector: ClickLoc with Protector
• -BR Approval: Country Specific

Key Performance Features

• Compatibility: Interchangeable with older 3300 RAM probes.
• Measurement Range: 1.5 mm (60 mils) linear range.
• Set Gap To: 1.0 mm (40 mils) for optimal performance.
• Sensitivity (ISF): 7.87 V/mm (+12.5% / -20%).
• Accuracy (DSL): Better than ±0.06 mm.
• Frequency Response: 0 to 10 kHz.
• Probe Resistance (0.5m): 4.0 Ω ± 0.5.
• Thread & Torque: M8x1 thread. Max torque 0.56 N•m.
• Materials: PPS Tip, 304 Stainless Steel Armored Case.
• Temperature: Operates from -52°C to +177°C.
• Seal: Viton® O-ring for pressure differential.

Installation Notes

1. Mount in M8x1 threaded hole. Hand-tighten plus slight torque.
2. Ensure minimum 13mm (0.5 in) target diameter for best results.
3. Connect the ClickLoc connector with its protective cover.
4. Set the initial gap to 1.0 mm from the target shaft.

Package & Guarantee

• One (1) new, original Bently Nevada 3300 NSv Probe.
• Part Number: 330904-00-10-05-01-BR.
• Factory Warranty: Full 12 months from shipment.
• Shipping: Fast global delivery via FedEx, UPS, and DHL.

Designed For Challenging Environments

Ideal for process compressors and applications requiring chemical resistance. Its compact size suits machinery with limited space. For more 3300 XL NSv Proximity Probes, browse our full range.

Professional FAQ & Selection Support

Product Details

• What does “Country Specific (BR)” approval mean?
• It means the probe meets specific national safety standards. The exact certification depends on the destination country’s requirements.
• How is the NSv probe different from the old RAM probe?
• The NSv probe has better chemical resistance for harsh processes. It is a direct mechanical and electrical replacement but offers improved durability.

Application Tips

• Can I use this on a very small shaft?
• The minimum target is 8.9mm, but 13mm is recommended. On smaller shafts, the output may change. Reduce the gap to minimize this effect.
• Why is the torque specification so low?
• The M8x1 thread is smaller and more delicate. Over-torquing can damage the threads or the probe case. Always use a torque wrench.

Ordering & Service

• What does your 12-month warranty cover?
• It covers defects in materials and workmanship for one year. Your order includes the genuine probe, warranty, and your choice of FedEx/UPS/DHL shipping. Questions? Contact us on WhatsApp: +86 158 8020 0923.
