Product Introduction: Compact Hazardous Area Probe
This Bently Nevada 3300 NSv Proximity Probe is a specialized sensor. It is designed for small spaces and hazardous environments. The M8x1 metric thread is compact. It includes FluidLoc cable and full safety certifications.
Product Configuration Details
Your exact model is 330904-04-14-10-12-05. This code defines all features.
- Base Product: 330904 (NSv Probe, M8x1, With Armor)
- Specification Tree:→ 04 : Unthreaded Length = 40 mm→ 14 : Case Length = 140 mm→ 10 : Cable Length = 1.0 meter→ 12 : Connector = ClickLoc, FluidLoc Cable→ 05 : Approvals = Multiple (CSA/ATEX/IECEx)
Technical Specifications
- Measurement Data▸ Linear Range: 1.5 mm (60 mils)▸ Recommended Gap: 1.0 mm (40 mils)▸ Sensitivity: 7.87 V/mm (200 mV/mil)▸ Frequency Response: 0 to 10 kHz
- Electrical Data▸ Probe Resistance: 4.2 Ω ±0.50 Ω (1.0m)▸ Cable Capacitance: 69.9 pF/m typical▸ Field Wiring: Max 305 meters with shield
- Mechanical Design▸ Thread: M8 x 1.0 metric▸ Case Material: Armored 304 Stainless Steel▸ Tip Material: Chemical-resistant PPS▸ Torque: 7.5 N•m recommended (first 3 threads)▸ Min Target Size: 13 mm diameter
- Certifications & Environment▸ Safety Approvals: ATEX, IECEx, CSA▸ Temperature: -52°C to +177°C▸ Pressure Seal: Viton® O-ring▸ Cable: FluidLoc prevents fluid ingress
Key Product Advantages
- Small M8 Thread: Fits compact mounting spaces on process compressors.
- Hazardous Area Certified: Ready for Zone 0/1/2 explosive atmospheres.
- FluidLoc Protection: Special cable stops oil migration completely.
- Chemical Resistance: Enhanced materials for harsh process environments.
- Backward Compatible: Direct replacement for older 3300 RAM probes.
Installation Instructions
- Install in M8x1 threaded hole. Max 15mm thread engagement.
- Use low torque: 7.5 N•m for first 3 threads, 11.3 N•m if fully engaged.
- Set initial gap to 1.0 mm (40 mils) from target shaft.
- Ensure target diameter is at least 13 mm for accurate measurement.
- Connect FluidLoc cable following hazardous area wiring codes.
Typical Applications
- Process gas compressors in oil & gas industry.
- Small bore machinery with limited mounting space.
- Hazardous chemical and pharmaceutical plants.
- Applications requiring M8 metric thread and fluid protection.
Expert FAQs
What is the main difference between 3300 XL and 3300 NSv probes?
3300 NSv Probes have a smaller M8 thread, lower resistance (4.2Ω), and are optimized for process compressors. XL probes typically have M10 or 3/8-24 threads and 7.5Ω resistance.
Why is the probe resistance lower (4.2Ω) than other models?
The NSv probe design uses a different coil. The 4.2Ω resistance is normal. It is electrically compatible with 3300 monitoring systems when properly calibrated.
Can I use this probe if my machine has an M10 thread?
No. This probe has a fixed M8x1 thread. You would need an adapter or should select an M10 probe. Browse our full range of 3300 NSv Proximity Probes for other options.
What does “FluidLoc cable” actually do?
The FluidLoc cable has a special internal seal. It stops oil or process liquid from traveling inside the cable jacket. This prevents leaks at the electrical connector.
Is the armor on this probe removable?
No. The stainless steel armor is permanently bonded to the probe case. It provides essential protection in high-vibration, high-risk environments.
