The Bently Nevada 330905-00-13-05-02-00 is a 3300 NSv Proximity Probe engineered for precision vibration monitoring in industrial environments. Featuring a 130 mm (5.1″) stainless steel case and 0.5 m (20″) armored cable, this probe offers reliable performance in harsh conditions. Designed as a direct replacement for 3300 RAM probes, it combines chemical resistance with backward compatibility for seamless system upgrades.
Technical Specifications
- Model: 330905-00-13-05-02-00
- Suffix Code Breakdown:
- -00: 0 mm unthreaded length (fully threaded)
- -13: 130 mm (5.1″) case length
- -05: 0.5 m (20″) cable length
- -02: ClickLoc™ connector + standard cable
- -00: No agency certifications required
- Electrical:
- DC Resistance: 4.0 Ω ±0.5 (0.5m length)
- Linear Range: 1.5 mm (60 mils) | Gap: 1.0 mm (40 mils)
- Scale Factor: 7.87 V/mm (±12.5%)
- Frequency Response: 0-10 kHz (±3 dB)
- Mechanical:
- Case Material: AISI 304 SST (corrosion-resistant)
- Tip Material: Polyphenylene Sulfide (PPS)
- Thread Torque:
- Full Engagement: 33.9 N·m (300 in·lb) max / 11.3 N·m (100 in·lb) recommended
- First 3 Threads: 22.6 N·m (200 in·lb) max / 7.5 N·m (66 in·lb) recommended
- Bend Radius: 25.4 mm (1.0″)
- Environmental:
- Operating Temp: -52°C to +177°C (-62°F to +351°F)
- Pressure Seal: Viton® O-ring (500 psi differential)
Key Applications
- Process gas compressors in refineries
- Steam turbine thrust monitoring
- Retrofitting 3300 RAM systems in chemical plants
