Description
Product Introduction
Meet the Bently Nevada 74712-03-10-02-00 two-wire transducer. This sensor is made for hot and tough places. It turns machine vibration into a clear signal. Setup is quick with its simple two-wire design. Trust it to watch over pumps, motors, and fans in heat.
Main Features & Benefits
- Extreme Heat Tolerance: Works reliably up to 400°F (204°C).
- Easy Wiring: Only needs two wires for power and data together.
- Strong Build: Tough metal housing protects the sensor.
- Accurate Angle: Pre-set to measure at a perfect 90-degree angle.
- Common Mount: Fits standard M10 x 1 threaded holes.
- Catches Low Speeds: Monitors slow vibrations from 270 RPM.
- Light & Easy to Handle: Weighs just over 1 pound.
Complete Technical Specifications
Product Identification
- Brand: Bently Nevada
- Full Model Number: 74712-03-10-02-00
- Type: Two-Wire Vibration Velocity Transducer
- Product Line: 74712 High-Temperature Series
Electrical & Signal Data
- Wiring Style: 2-wire, loop-powered.
- Output: Industry-standard 4-20 mA signal.
- Useful Frequency Range: 4.5 Hz to 1 kHz.
- Measurement Range: 0 to 1.0 inch per second peak velocity.
- Output Sensitivity: ~500 mV per inch/second.
- Linearity: Typically better than ±2%.
- Required Power: 12-30 VDC power supply.
Mechanical Specifications
- Fixed Mounting Angle: 90° (±2.5°).
- Mounting Thread Size: M10 x 1.0 mm pitch.
- Body Diameter: 41 mm (1.6 inches).
- Total Height: ~102 mm (4.0 inches).
- Case Material: Stainless Steel.
- Product Weight: 0.48 kg (1.06 lbs).
- Electrical Connection: Integral cable or top-entry connector.
Environmental Ratings
- Continuous Temp Range: -20°F to +400°F (-29°C to +204°C).
- Short-Term Temp Max: Up to +428°F (+220°C).
- Shock Rating: Can survive 1000g shocks.
- Vibration Limit: Operates under 50g vibration.
- Sealing (Typical): IP65 (Dust-tight, water jet resistant).
Warranty & Shipping Info
Your purchase is protected by a full 12-month warranty. We deliver worldwide via FedEx, UPS, and DHL express services. Track your order easily with the link we provide.
Frequently Asked Questions
Application Questions
What machines need this high-temperature sensor?
Use it on equipment near engines, ovens, steam systems, or hot processes. It is ideal for areas where standard sensors would fail from heat.
Can I connect this directly to my PLC?
Yes, if your PLC has a 4-20 mA input card. The two-wire design connects directly. No extra signal conditioner is needed.
Installation & Tips
How tight should I screw in the transducer?
Use a wrench to tighten firmly. Do not over-tighten. The metal mounting base should sit flush against the machine surface for a good reading.
My reading is stuck at 4 mA. What does this mean?
A 4 mA output usually means zero vibration. First, check if the machine is running. If it is running, there may be a wiring problem or the sensor is damaged.
Buying Guidance
I need a sensor for a very hot pump. Is the 74712-03-10-02-00 the right choice?
Yes. The 74712-03-10-02-00 is specifically designed for high-temperature pumps and similar applications. Just verify your mounting hole is M10 x 1 threaded.
