Description
Bently Nevada 3300 XL 8 mm Proximity Probe
Advanced industrial sensor (330103-00-07-10-02-00) for vibration analysis and position detection, featuring extended temperature resilience and hazardous-area compliance. Ideal for critical machinery protection.
Configuration Codes
- Part No.: 330103-00-07-10-02-00
- Unthreaded Length Option : 00 = 00mm
- Case Length: 07 (70 mm)
- Total Length Option : 10 1.0 meter (3.3 feet)
- Connector: 02 (ClickLoc® mini-coaxial)
- Agency Code: 00 (No certification required)
Electrical & Mechanical
- Thread Engagement: M10x1 (15 mm max)
- Cable Gauge: 16-24 AWG shielded triad
- Frequency Response: ±3% up to 12 kHz (305 m cable)
- Voltage Output: -1 to -17 Vdc linear range
Material Specifications
- Tip: PPS (Polyphenylene sulfide)
- Housing: AISI 303/304 SST
- Seal: Viton® O-ring (non-pressure-tested)
- Weight Density: 323 g/m (11.4 oz/ft)
Environmental Limits
- Thermal Cycling:
– Standard: 500 cycles (-52°C ↔ +177°C)
– Extended: 200 cycles (-52°C ↔ +260°C)
- Humidity Endurance: 1,344 hrs @ 93% RH
- Vibration Resistance: 20 g peak (10-2000 Hz)
Certifications
- ATEX: II 2G Ex ec IIC T4-T6 Gb
- IECEx: Ex ec IIC T4-T6 Gb
- UL/CUL: Class I Div 2 Groups A-D
- Compliance: IEC 60079-0/-11/-14
Critical Note: Signal integrity degrades 0.05%/m beyond 200m cable length. For pressure seal validation or custom drawings, contact sales@ubestplc.com.
Explore more detailed information in official datasheet here: 3300 XL 8 mm Proximity Transducer System Datasheet
