Bently Nevada Proximity Probe Without Armor 330908-00-08-10-02-00

Description

3300 NSv Proximity Probe – Model 330908-00-08-10-02-00

Description

This 3300 NSv Proximity Probe is a high-quality sensor for vibration monitoring. It is made in the U.S.A. with no armor, making it lightweight and easy to install. The probe has a 3/8-24 UNF thread and uses a miniature coaxial ClickLoc connector for quick setup. Key features include a stainless steel case and a polyphenylene sulfide (PPS) tip for durability. The cable is 1.0 meter long (39 inches) and insulated with fluoroethylene propylene (FEP). Ideal for industrial use, it offers reliable performance in tough conditions.

Technical Data

Brand: Bently Nevada
Model: 330908-00-08-10-02-00
Full Suffix Information:

• -00 (Unthreaded Length: 0 in)
• – 08 (Case Length: 0.8 in)
• – 10 (Cable Length: 1.0 m)
• – 02 (Connector: Miniature Coaxial ClickLoc)
• – 00 (Approval: Not Required)

Key Specifications

• Range: Not specified (general proximity sensing).
• Accuracy: Based on resistance tolerance.
• Output Signal: 75 Ω coaxial resistance output.
• Probe Resistance: 4.2 ± 0.5 ohms at 1.0 m length.
• Operating Temperature: -52°C to +177°C (-62°F to +351°F). Avoid long exposure below -34°C (-30°F) to prevent seal damage.
• Storage Temperature: Same as operating range.
• Weight: 14 to 150 g (0.5 to 5.3 oz).
• Case Material: AISI304 stainless steel.
• Tip Material: Polyphenylene sulfide (PPS).
• Cable: 75 Ω coaxial, FEP insulated, 1.0 m length.

Installation Guide

• Use a 3/8-24 UNF thread for mounting.
• Max thread engagement: 0.563 in.
• Torque settings: Max 33.9 N•m (300 in•lb), Recommended 11.3 N•m (100 in•lb). Apply carefully to avoid damage.

Compatibility

Works with systems using miniature coaxial ClickLoc connectors. Fits standard 75 Ω coaxial setups. Not for high-pressure environments without testing.

Packaging List and Warranty

• Includes: Probe unit, ClickLoc connector, standard cable
• Warranty: 12 months from delivery date

Shipping Options

Fast delivery via FedEx, UPS, or DHL. Tracking provided for all orders.

FAQ

• Q: What is the temperature limit for this probe?
  A: Operates from -52°C to +177°C. Do not store below -34°C for long periods.
• Q: Is the probe waterproof or pressure-rated?
  A: It has a Viton O-ring seal but is not tested for pressure. Use in dry, controlled environments.
• Q: Can I use a different cable length?
  A: Yes, standard lengths include 0.5, 1, 5, or 7 meters. This model has 1.0 m.
• Q: How do I connect the probe?
  A: Use the ClickLoc connector for easy, secure links to monitoring systems.
