CSA/ATEX Bently Nevada 330104-04-09-50-02-05 Probe | 5m Armored Sensor

Description

Certified Armored 5-Meter Probe

The Bently Nevada 3300 XL 8mm Probe is built for certified sites. Model 330104-04-09-50-02-05 comes with full agency approvals. Its 5-meter cable and armored case suit tough, regulated plants. Get reliable monitoring with compliance.

Complete Feature Analysis

Your model number 330104-04-09-50-02-05 includes these key features:

• Base Model 330104: Armored, M10x1 Thread
• -04 | Unthreaded: 40 mm smooth section
• -09 | Case Length: 90 mm total length
• -50 | Cable: 5.0 meters long (16.4 ft)
• -02 | Connector: Standard ClickLoc
• -05 | Approvals: CSA, ATEX, IECEx Certified

Primary Specifications

• Product Family: 3300 XL 8mm Proximity Probes, Metric
• Mounting: M10 x 1.0 thread. Max 15mm engagement.
• Key Feature: 5.0 meter integrated cable. Use only with 5-meter Proximitor.
• Electrical Data: Probe resistance is 8.73 Ω (±0.50).
• Performance: 2 mm linear range. Set gap to -9 Vdc.
• Construction: Armored SST case, PPS tip, Viton® seal.
• Temperature: Standard operating range -52°C to +177°C.
• Safety Ratings: Approved for use in ia (Zone 0) and nA/ec (Zone 2) systems.

Global Safety Certifications

• CSA: Certified for Canada and North America.
• ATEX: Approved for European hazardous locations.
• IECEx: International certification for explosive atmospheres.
• This eliminates the need for external safety interface drawings in many cases.

Straightforward Setup

1. Mount the probe in the M10x1 hole. Use correct torque.
2. Route the 5-meter cable carefully to the Proximitor.
3. Connect the ClickLoc connector to the 5-meter Proximitor sensor only.
4. Power the system and adjust the gap to -9 Vdc.

Your Order Includes

• One (1) Bently Nevada 3300 XL 8mm Armored Probe.
• Full part number: 330104-04-09-50-02-05.
• Warranty: Comprehensive 12-month coverage.
• Global Delivery: Shipped via FedEx, UPS, or DHL.

Designed For Critical Sites

Essential for oil & gas, chemical, and power plants requiring certified equipment. The long 5m cable reduces connection points. Explore other 3300 XL 8mm Probes for different lengths.

Essential Q&A for Buyers

Product Capabilities

• What does the “05” agency approval option mean?
• It means this probe model is pre-certified by CSA, ATEX, and IECEx. You can install it in hazardous areas without additional component-level certification.
• Why must the 5-meter probe only be used with a 5-meter Proximitor?
• The system calibration is matched. Using it with a 9-meter Proximitor will cause incorrect gap voltage and measurement errors.

Application Expertise

• How do I handle the long 5-meter cable during installation?
• Coil excess cable neatly. Avoid sharp bends. Secure it with ties away from heat and moving parts. Do not cut the cable.
• Is the armored case electrically grounded?
• Yes, through the mounting threads. Ensure good metal-to-metal contact with the machine casing for proper grounding and noise shielding.

Purchasing & Logistics

• What is your policy for certified products like 330104-04-09-50-02-05?
• We supply genuine, certified probes with traceability. They include a 12-month warranty and ship via FedEx/UPS/DHL. For compliance questions, message us on WhatsApp at +86 158 8020 0923.
