Description
Product Overview
Emerson SE4035S2B1 is a 2 x AO Card with 8 channels. It outputs 4-20 mA signals. Supports HART communication. Comes with a redundant 8-channel terminal block. Perfect for process control systems.
Brand: Emerson
Model: SE4035S2B1
Type: Analog Output Module
Series: SE4000 Series
Also explore GE Versamax series for more I/O options.
Key Features
Eight independent output channels
Supports 4 to 20 mA devices
Full signal range: 1 to 23 mA
14-bit resolution for precise control
No calibration needed – saves time
Optical isolation per channel (1500V DC tested)
HART pass-through for AMS Device Manager
Redundant terminal block included
Optional 2.0 A fuse on terminal block
Open-loop detection below 0.70 mA
Technical Specifications
Channel Configuration
Total channels: 8
Device types: 4 to 20 mA
Signal range: 1 to 23 mA
Accuracy
-40°C to 60°C: 0.25% of span
60°C to 70°C: 0.4% of span
Resolution & Conversion
D/A converter: 14-bit
Calibration
None required – factory set
Power Consumption (Local Bus, 12V DC Nominal)
Simplex mode: 120 mA typical, 150 mA max
Redundant mode: 175 mA typical, 250 mA max
Field Circuit Power
300 mA max at 24V DC (±10%)
Isolation
Optical isolation per channel
Tested to 1500V DC
Output Compliance
20 mA at 21.6V DC into 700 Ω load
Open-Loop Detection
Threshold: <0.70 mA
Fuse Option
2.0 A (available on terminal block)
HART Communication
Pass-through for AMS Device Manager
Reports HART variables and status
Scan time: 600 to 800 ms per enabled channel
Installation & Compatibility
Plugs into SE4000 series backplane
Works with Emerson DeltaV systems
Compatible with HART-enabled field devices
Use with redundant power supplies for high availability
Terminal block supports field wiring
Maintenance & Service
No routine calibration required
Check LED indicators for channel status
Replace fuse if open-loop detected
Keep terminal block screws tight
Clean with dry cloth only
Diagnostic Capabilities
Detects open-loop conditions (<0.70 mA)
Monitors output current per channel
Reports HART device status
Alerts on over-temperature conditions
Provides fault indication via LEDs
FAQ – Frequently Asked Questions
What is the difference between simplex and redundant modes?
Simplex uses one power path. Redundant uses two for backup. Choose redundant for critical processes.
Can I mix HART and non-HART devices on this card?
Yes. Enable HART per channel. Non-HART channels work normally.
How do I know if the fuse has blown?
The card reports an open-loop condition. Check LED status. Replace the 2.0 A fuse if needed.
What happens if ambient temperature exceeds 70°C?
Accuracy may drop. Keep temperature below 70°C. Use cooling fans if necessary.
Is this card compatible with third-party PLCs?
It works best with Emerson DeltaV. For other PLCs, check HART protocol support.
How long does shipping take?
We ship via FedEx (3-5 days), UPS (3-7 days), or DHL (2-4 days). Express options available.
What is your return policy?
Returns accepted within 30 days. Product must be unused. Contact us for RMA number.
Do you offer bulk discounts?
Yes. Contact us for orders of 5+ units. We provide volume pricing.
What documentation comes with this card?
Includes quick start guide. Full manual available online. Installation drawings included.
Can I use this in hazardous areas?
Check your system certification. This card is not intrinsically safe. Use external barriers if needed.
Selection Guide – Which AO Card to Choose?
Choose SE4035S2B1 (this model) for:
8 analog output channels
HART communication needs
Redundancy requirements
Standard 4-20 mA devices
Choose non-HART version if:
You don’t use HART devices
Budget is a concern
Choose higher channel count if:
You need more than 8 outputs
Space is limited in the cabinet
Warranty & Shipping
12-month warranty against defects
Covers manufacturing faults only
Fast shipping via FedEx, UPS, or DHL
Tracking number provided
Express delivery available on request
Ordering & Support
Questions? Contact us on WhatsApp: +86 158 8020 0923
We offer technical support during installation. Bulk orders welcome.
