Emerson SS4303T01 LS AI CHARM | 4-20mA HART Input Module

Description

Product Intro

The Emerson SS4303T01 is a LS AI 4-20 mA HART CHARM. It is part of the DeltaV SIS™ Electronic Marshalling system. This CHARM reads analog inputs from field devices. It supports HART communication for smart instruments. The module offers high accuracy and fault isolation.

System Overview (Hierarchical)

• DeltaV SIS Electronic Marshalling
  • CHARM Smart Logic Solver Carrier (DIN rail mounted, supports redundant solvers, power, and Ethernet)
  • CHARM Smart Logic Solver (handles logic for up to 96 LS-CHARMs)
  • CHARM Baseplate (holds 12 LS CHARMs and terminal blocks)
    • Terminal Blocks (removable, for field wiring)
  • LS CHARM (characterizes each signal, provides isolation)
  • Bus Termination (adds robustness at the end of the bus)
  • Cable Extenders (for flexible carrier mounting)

Key Features

• Flexible Marshalling: Wire signals in any order. No need for cross-wiring.
• Built-in Protection: Limits current and protects against ground faults.
• Surge Protection: Meets EMC industry standards.
• Fuse Function: Acts like a fuse in extreme overvoltage.
• Easy Maintenance: Partially eject the CHARM to disconnect field wiring safely.
• Auto-Sensing: System detects new LS CHARMs online.

Technical Specifications (Table Format)

Signal Range & Accuracy (Hierarchical)

• 0 to 5 V
  • Accuracy at 25°C: ± 0.005 V
  • Temp Drift: ± 0.0005 V/°C
  • Resolution: 0.00008 V
• 0 to 10 V
  • Accuracy at 25°C: ± 0.010 V
  • Temp Drift: ± 0.001 V/°C
  • Resolution: 0.00015 V
• 1 to 5 V
  • Accuracy at 25°C: ± 0.005 V
  • Temp Drift: ± 0.0005 V/°C
  • Resolution: 0.00006 V
• -1 to +1 V
  • Accuracy at 25°C: ± 0.0025 V
  • Temp Drift: ± 0.0002 V/°C
  • Resolution: 0.00003 V
• -5 to +5 V
  • Accuracy at 25°C: ± 0.005 V
  • Temp Drift: ± 0.0005 V/°C
  • Resolution: 0.00015 V
• -10 to +10 V
  • Accuracy at 25°C: ± 0.010 V
  • Temp Drift: ± 0.001 V/°C
  • Resolution: 0.00030 V

Installation & Flexibility

• Mounting: Snaps easily onto a standard DIN rail.
• System Layout: Carrier at top, up to 8 baseplates below, terminator at bottom.
• Wiring: Connect field multi-cores in any order. Install the correct LS CHARM.
• Flexibility: Use baseplate extenders and cables for custom enclosures.

Compatibility

• System: Designed for DeltaV SIS Electronic Marshalling.
• Network: Supports DeltaV SIS Smart Switches on the Local Safety Network (LSN).
• Controller: Works with SZ controllers via the LSN and Area Control Network.
• Software: Requires DeltaV v14.3 or newer for the yellow Keylock feature.

Professional FAQ

• What happens if I wire the input incorrectly?
  The CHARM limits current and protects the system. In extreme cases, it acts like a fuse to save other channels.
• Can I change a CHARM while the system is running?
  Yes. The system auto-senses new CHARMs online. You do not need to shut down.
• How do I safely work on a connected field device?
  Partially eject the LS CHARM. This locks it out and disconnects field wiring safely.
• What is the Keylock for?
  It is a new feature in v14.3. It inhibits the unlock command to all CHARMs on the network. It uses a yellow plastic part.
• Do I need to calibrate this module?
  No. The SS4303T01 requires zero calibration. It is ready to use out of the box.

Buying Guide

• 1. Confirm Your System: Must be DeltaV SIS with Electronic Marshalling.
• 2. Signal Type: Choose the right range (e.g., 0-5V, 1-5V) for your sensor.
• 3. Check Quantity: One CHARM per channel. Max 96 per Solver.
• 4. Plan Layout: Use extenders if you need to spread baseplates in your cabinet.
• 5. Software Version: Ensure your system runs v14.3 or higher for full feature support.
