Description
Product Description
The Flexem FL8-E16-D is a compact motion CPU module for fast control tasks. It supports 16-axis EtherCAT motion and high-speed pulse channels. The unit uses a 4-core 1GHz CPU for quick logic work. It fits machines that need stable speed and clear motion paths. It runs many field protocols and links with many Flexem cards.
The module offers simple setup. It holds wide memory space and strong data tools. It supports program download by Type-C. The unit fits harsh plants and long working cycles.
Technical Specifications
- Brand: Flexem
- Model: FL8-E16-D
- 4-core 1GHz CPU for fast logic
- 2GB internal memory and 8GB disk space
- 16-axis EtherCAT control with pulse mode
- 6 channels of 200kHz pulse output
- 7 channels of 200kHz pulse input
- 8 digital inputs and 8 NPN digital outputs
- 2 Ethernet ports, 100M each
- 1 EtherCAT main port with up to 72 sub nodes
- 2 RS485 ports for serial tasks
- 1 CAN channel
- Left expansion for 4G Cat1, WiFi, or serial cards
- Right expansion up to 31 modules
- Program space: 32M
- User data: 128M
- Data areas: I 128KB, Q 128KB, M 512KB, Retain 800KB
- Unlimited other variables
- Type-C U disk for download and storage
- Support for electronic cam and gear
- Protocols: EtherCAT, Modbus-TCP, Modbus-RTU, CANopen, OPC UA
- DC 24V ±20% supply
- Built-in RTC
- Programming languages: IL, LD, ST, SFC, CFC, FBD
Performance Highlights
- Wide speed range for motion paths
- Fast response for small step tasks
- Stable control for long duty cycles
- High noise immunity for plant floors
- Clear data logs for field checks
Installation Guide
- Mount on a clean and dry panel
- Keep space for air flow
- Check DC 24V wiring before power on
- Link EtherCAT chain from the main port
- Follow I/O marks to avoid wrong wiring
- Lock expansion cards before use
Commissioning and Maintenance
- Use Type-C port for quick program load
- Check I/O map after wiring
- Run motion test with slow speed first
- Review error logs after long runs
- Clean dust from vents at set times
Compatibility Information
- Works with most EtherCAT servos
- Fits Flexem FL8 series expansion cards
- Supports mixed field protocols
- Fits many SCADA and MES links
Certifications
- Industry EMC class
- Meets common automation safety needs
Package List
- FL8-E16-D CPU module
- Quick guide
- Factory test sheet
Warranty
- 12-month warranty from delivery date
- Free support for normal use issues
Shipping Methods
- FedEx
- UPS
- DHL
Typical Applications
- High-speed pick and place
- Packaging and cutting
- Robot units
- Electronics assembly
- Light conveyor lines
Diagnostic Features
- Real-time EtherCAT state checks
- Clear warnings for I/O faults
- Clock logs for cycle events
- Fast fault trace for pulse tasks
FAQ
- How do I start setup
- Load the tool, link power, then scan the device.
- What axis count fits best
- Use all 16 axes for complex motion systems.
- Can I link old servo units
- You can link most units that support EtherCAT or pulse.
- How do I avoid noise issues
- Use short ground wires and keep power lines apart.
- How do I copy one program to many units
- Use the Type-C port and keep a clean file.
