Description
Product Overview
Flexem FR-T0400K is a
4-channel temperature acquisition module
built for precise industrial monitoring.
It supports many sensor types.
One module fits many tasks.
The slim design saves panel space.
DIN rail mounting speeds setup.
Core Advantages
- 4 independent input channels for compact systems
- Wide sensor compatibility reduces spare parts
- Stable accuracy across temperature ranges
- Low power draw for energy-efficient panels
- Slim housing suits dense control cabinets
Supported Sensors
- Thermocouples: K, J, R, S, B, E, T, N, C
- Resistance sensors: PT700, PT1000, Cu50, Cu100
- Nickel sensors: NI100, NI1000
- NTC temperature sensors
Measurement Ranges
- PT700: -200 to 850 °C
- PT1000: -200 to 600 °C
- Cu50: -50 to 150 °C
- Cu100: -50 to 150 °C
- NI100: -60 to 180 °C
- NI1000: -60 to 180 °C
Accuracy and Performance
- Thermocouple accuracy: ±0.3% or ±1 °C
- NTC accuracy: ±0.1% or ±1 °C
- Reference condition: 25 °C ambient
- Resolution: High-precision digital sampling
- Response time: Fast thermal signal capture
- Linearity: Optimized for industrial sensors
Electrical Characteristics
- Power supply: 5.0 VDC
- Current consumption: Max. 50 mA
- Input isolation: Designed for signal stability
- Noise immunity: Strong resistance to EMI
Mechanical Specifications
- Dimensions: 111 x 18 x 76 mm
- Weight: Approximately 65 g
- Mounting method: 35 mm DIN rail
Installation and Use
- Mount directly onto DIN rail
- Match sensor type before wiring
- Secure terminals to avoid drift
- Verify readings during first startup
Typical Applications
- Process temperature monitoring
- Furnace and heating systems
- Plastic and metal processing lines
- Energy and utility control panels
- Machine condition supervision
Warranty and Shipping
- 12-month warranty from shipment date
- Shipping via FedEx, UPS, or DHL
- Protective packaging for global delivery
FAQ
- Is cold junction compensation built in?
- Yes. It improves thermocouple stability.
- Can different sensor types mix on one module?
- Yes. Each channel supports flexible setup.
- What helps keep readings accurate long term?
- Use shielded cables and stable grounding.
- Is the module suitable for high heat areas?
- Yes. Keep it within rated ambient limits.
- What is a common field practice tip?
- Label sensors clearly during installation.
