Description
IC200MDL329 8-Channel Isolated AC Output Module
Control industrial equipment with precision using this robust 120VAC output module. Designed for reliability with optical isolation and surge protection.
Key Features
- 8 isolated outputs for independent load control
- LED indicators for instant status monitoring
- Built-in snubber and MOV protection per channel
- Supports high inrush currents (5.0A for 20ms)
Technical Specifications
- Model: IC200MDL329 (Full suffix: IC200MDL329)
- Output Type: 120VAC switching
- Voltage Range: 85-132VAC (47-63Hz)
- Current Capacity: 0.5A max per channel
- Isolation: 250VAC continuous/1500VAC 1min
- Response Time: <½ AC cycle on/off
- Backplane Power: 5V DC, 70mA max
Installation Guide
Mount on DIN rail. Connect external 120VAC power source to terminal block. Load wiring: 18-22 AWG recommended.
Compatibility
Works with VersaMax PLC systems. Verify backplane compatibility before purchase.
Packaging Includes
- 1x IC200MDL329 module
- Terminal connector
- Installation sheet
Shipping & Warranty
Delivery: FedEx/UPS/DHL (2-5 business days)
Warranty: 12 months against defects
Industrial Applications
- Conveyor motor control
- HVAC damper actuators
- Industrial lighting systems
FAQ
Q: Requires external power?
A: Yes – 85-132VAC power supply needed
Q: Minimum load requirement?
A: 10mA per channel minimum
Q: Leakage current?
A: <2mA at 132VAC
