GE Fanuc IC200UDD110 | 28-Point Micro Controller

Description

IC200UDD110: 28-Point Micro PLC for Compact Automation

GE Fanuc’s IC200UDD110 combines 16 digital inputs and 12 transistor outputs in a DIN-rail mounted package. Features high-speed counters (10kHz), PWM outputs, and robust 1500V isolation. Ideal for machine control with flexible I/O grouping.

Technical Specifications

• Brand: GE Fanuc
• Model: IC200UDD110
• Input Points: 16x 24Vdc (4 isolated groups)
• Output Points: 12x transistor (24Vdc)
• Output Current:
  4x 1A (Q1,Q2,Q11,Q12) +
  8x 0.75A (Q3-Q10)
• HSC/PWM: 4x 10kHz counters, 4x 5kHz outputs
• Power Supply: 19.2-30Vdc (5W rating)
• Isolation: 1500V RMS (field-logic)
• Response Time: 0.1ms (outputs), 100µs (HSC)
• Weight: 460g (1.01 lbs)

Installation Guide

• Mount on DIN rail in control cabinet
• Connect input groups to separated commons
• Provide external fusing for all outputs
• Ensure power supply within 19.2-30Vdc range

Diagnostics & Maintenance

• Monitor LED indicators for I/O status
• Check voltage thresholds: ON ≥15Vdc, OFF ≤5Vdc
• Prevent overload: Max 0.5A/point on Q3-Q10
• Maintain ambient temperature below 55°C

Packaging List

• IC200UDD110 PLC unit (1)

Shipping Methods

Fast global delivery via FedEx, UPS, DHL with tracking.

Frequently Asked Questions

• Max output load?
• 1A for Q1/Q2/Q11/Q12; 0.75A for others
• HSC types supported?
• Up to four Type A or mixed A+B
• Power consumption?
• 0.2A typical @24Vdc
• Input isolation?
• 500V RMS between groups
• Warranty period?
• 12 months from delivery
