GE IS200ERBPG1ACA Exciter Regulator Backplane
The IS200ERBPG1ACA serves as the central connection hub for EX2100 excitation control systems. This robust backplane enables seamless communication between all mounted circuit boards. Designed for both simplex and redundant applications, the IS200ERBPG1ACA ensures reliable performance in turbine control environments.
Key Advantages
- Central connectivity for all system boards
- Supports both simplex and redundant configurations
- Built-in board identification system
- Multiple power distribution options
- Easy maintenance and upgrades
- Compatible with Mark VI and EX2100 systems
Technical Specifications
- Brand: General Electric
- Model: IS200ERBPG1ACA
- Series: EX2100 Excitation Control
- Product Type: Exciter Regulator Backplane
- Connector Types: 96-pin & 128-pin DIN
- Board Slots: 12 available channels
- Analog Input: 4-20 mA standard
- Analog Output: 0-20 mA current
- Voltage Range: ±5 V common mode
- Lead Resistance: 15Ω maximum
- Dimensions: 8.26 cm x 4.19 cm
- Temperature Range: -30°C to +65°C
- Mounting: 3U/6U VME compatible
Compatible Boards
Works with IGBT, EPSM, ERDD, ERIO, ACLA, DSPX boards. Supports external fan power. Provides board ID serial bus. Easy integration with existing systems.
Shipping & Warranty
Fast global delivery via FedEx, UPS, DHL. All orders include 12-month warranty protection. Quality tested before shipping.
Professional FAQ
- What systems is this backplane compatible with?
- It works with EX2100 excitation control and Mark VI turbine systems.
- How many boards can connect to this backplane?
- It supports multiple boards including IGBT, EPSM, ERDD, and others.
- What connector types does it use?
- It features 96-pin and 128-pin DIN connectors for board connections.
- Does it support redundant systems?
- Yes, it includes master selection jumpers for simplex or redundant applications.
- What is the board identification feature?
- It has a serial bus that reads barcode data from each installed board.
