GE Fanuc IC200MDL144 Discrete Input Module – 4-Channel AC Isolation
Product Overview
High-voltage 240V AC input module for VersaMax systems. Features 4 fully isolated channels with individual status LEDs. Ideal for industrial sensing applications without external power requirements.
Technical Specifications
| Brand | GE Fanuc |
| Series | VersaMax |
| Model | IC200MDL144 |
| Input Channels | 4 isolated |
| Operating Voltage | 240V AC (0-264V AC range) |
| Frequency | 47-63 Hz |
| Isolation | 2000V AC (1min), 500V AC continuous |
| Backplane Power | 5V DC, 30mA max |
| Response Time | 1 cycle (16-20ms) |
Installation Steps
- Power down VersaMax rack (optional for hot-swap)
- Snap module into compatible carrier
- Connect 240V AC field wiring
- Verify backplane LED illuminates
- Check channel status LEDs during operation
Package Includes
- IC200MDL144 Module
- Installation guide
- Terminal labels
Shipping Info
Global delivery via FedEx, UPS, DHL. Compact design – ships with standard industrial components. Tracking provided.
FAQ
External power required?
No – Powered entirely from backplane
Maximum input voltage?
264V AC continuous operation
Status indicators?
4 channel LEDs + backplane power LED
Compatible with IC200CHS003 carrier?
No – Check alternative carriers
Response time at 50Hz?
20ms maximum (1 cycle)
