Description
Product Overview
The HIMA F8627X is a Fast Ethernet communication module. It supports safeethernet, MODBUS TCP slave, and OPC DA/A&E via HIMA OPC server. Consequently, this module enables ELOP II programming over Ethernet (from ELOP II V4.1). Furthermore, it works with new CPUs: F8650X/F8652X (safe CPU for H51q/H41q) and F8651X/F8653X (non-safe CPU). For reference, older F8627 and F8628 remain available. As a result, one bus handles safety control, programming, and communication. Thus, no extra networks are needed. Moreover, it is ideal for open system technology.
Key Advantages
Single network for configuration, safety, and data
MODBUS-TCP communication via Ethernet
OPC Alarm & Event (A&E) via HIMA OPC server
Supports redundant or mono safety communication
Uses 100 Base-T interface with RJ45 connector
Technical Specifications
Brand: HIMA
Model: F8627X
Type: Fast Ethernet Communication Module
Protocols: safeethernet, MODBUS-TCP slave, OPC DA, OPC A&E
Programming: ELOP II over Ethernet (V4.1 or higher)
Interface: 100 Base-T, RJ45
System compatibility: H41q and H51q systems
Mounting: 19-inch module, 3 height units (3 x 44.45 mm), 4 width units (4 x 5.08 mm)
Measurement range: Ethernet data packets (full duplex)
Frequency response: 100 MHz typical
Sensitivity: IEEE 802.3 compliant
Linearity: Digital protocol, no signal distortion
Resolution: Standard Ethernet frame (64 to 1518 bytes)
Temperature range (operating): 0°C to +60°C
Temperature range (storage): -25°C to +70°C
Environmental tolerance: IP20 protection, 5% to 95% RH non-condensing
Noise immunity: EN 61000-6, EN 50082-2, high EMC resistance
Standards & Certifications: IEC 61131-2, EN 50081-2, IEEE 802.3, EN 50170
Dimensions (WxHxD): 4 x 5.08 mm (width units) x 3 x 44.45 mm (height units) x 160 mm approx.
Weight: approx. 0.5 kg
Installation Guide
Fits 19-inch racks for H41q/H51q systems
Uses 3 height units (HU) and 4 width units (WU)
Insert module into compatible backplane
Then connect RJ45 cable to 100 Base-T port
No special tools required
Finally, allow space for ventilation
Commissioning & Maintenance Convenience
ELOP II auto-detects module via Ethernet
Plug and play for MODBUS TCP slave mode
Hot-swappable in redundant setups
LED status indicators for power, link, activity
No routine calibration needed
Likewise, firmware updates occur via Ethernet
Compatibility Notes
Works with HIMA F8650X/F8652X (safe CPUs)
Works with HIMA F8651X/F8653X (non-safe CPUs)
Supports older HIMA CPUs via safeethernet
Use with HIMA OPC server for DA and A&E
Compatible with standard MODBUS TCP masters
However, not compatible with F8627 or F8628 firmware directly
Diagnostic Capabilities
Built-in self-test on power-up
Link integrity test per IEEE 802.3
Error counters for dropped packets
OPC server status visible via ELOP II
safeethernet supervision detects cable breaks
Redundancy monitoring for dual modules
As a result, it logs communication timeouts
Typical Applications
Safety controller programming in H41q/H51q systems
MODBUS TCP slave for factory automation
OPC Alarm & Event to SCADA systems
Redundant safety networks in oil and gas
Open system integration in power plants
Therefore, remote diagnostics via Ethernet
Frequently Asked Questions (FAQ)
Can I use F8627X with older HIMA CPUs?
Yes, but only via safeethernet. However, ELOP II programming over Ethernet requires ELOP II V4.1 or newer.
Is MODBUS TCP slave enabled by default?
No. You must enable it in ELOP II configuration. By default, it runs in safeethernet mode.
What is the maximum cable length for 100 Base-T?
100 meters with CAT5 or better shielded cable. Consequently, keep switches close to the module.
How do I know if redundancy is working?
Check both modules’ LEDs. Green means active. Furthermore, use ELOP II diagnostics view.
Can I replace F8627 with F8627X directly?
No. First, check CPU compatibility. For instance, F8627X requires F8650X/F8652X or F8651X/F8653X CPUs.
What OPC versions are supported?
OPC DA (Data Access) and OPC A&E (Alarms & Events) via HIMA OPC server.
Does the module support DHCP?
No. Use static IP addresses in ELOP II. Otherwise, communication will fail.
My module shows no link. What should I do?
First, check RJ45 connection. Then verify cable type (straight or crossover). Finally, test with known good device like 3300 XL 11 mm Proximity Probes if available.
Experience-based tip:
Always update ELOP II to V4.2 or higher for best MODBUS TCP stability. For redundant systems, wire both modules to separate switches. Otherwise, a single switch failure breaks both links.
Which redundant setup works best?
Use two F8627X modules with two separate Ethernet switches. As a result, you avoid a single point of failure.
Packing List
One HIMA F8627X communication module
One printed quick start guide
No cables or connectors included
Warranty & Shipping
12-month warranty against manufacturing defects
Shipping via FedEx, UPS, or DHL
Tracking number provided within 24 hours
International shipping available
Contact & Support
For inquiries: +86 158 8020 0923 (WhatsApp)
Reference Link
For similar hardware needs, check 3300 XL 11 mm Proximity Probes.
