IC200MDL330 – 120VAC Output Module with 16 Isolated Points
Control industrial devices reliably with this 16-point isolated output module. Perfect for automation systems requiring 120VAC switching. Features optical isolation and rugged protection for harsh environments.
Technical Data
- Brand: GE Fanuc
- Model: IC200MDL330
- Series: VersaMax
- Output Points: 16 isolated channels
- Voltage Range: 85-132VAC (47-63Hz)
- Current Capacity: 0.5A per point (5.0A inrush)
- Response Time: <½ cycle
- Isolation: 250VAC continuous (1500VAC/1min)
- Power Consumption: 140mA max @5V
Core Specifications
- Electrical: 2.0V max voltage drop
- Environment: -20°C to 60°C operating
- Protection: Snubber/MOV per output
- Indicators: Per-point status + system OK LED
Discontinuation Notice
This product is actively supported with no replacement required.
Installation Guide
- Mount on DIN rail
- Connect backplane securely
- Apply 120VAC power (85-132VAC)
- Wire outputs to devices
Diagnostics & Maintenance
- Check LED status indicators daily
- Clean with dry cloth monthly
- Verify connections quarterly
- No software diagnostics
Package Contents
- IC200MDL330 module
- Terminal labels
- Installation sheet
- 12-month warranty
Shipping Options
Fast global delivery via: FedEx • UPS • DHL
Industry Applications
- Conveyor control systems
- Packaging machinery
- HVAC components
- Industrial lighting
FAQ
Q: Are points individually fused?
A: No, each output has MOV/snubber protection
Q: Requires external power?
A: Yes, 120VAC supply needed
Q: Water-resistant?
A: Designed for dry locations only
