IC200MDL331 120V AC Output Module
DESCRIPTION
Formerly GE, now Emerson’s IC200MDL331 delivers 8-point isolated AC output for Versamax systems. Features 2A per point capacity and individual channel isolation. Handles high-inrush loads (20A) with built-in MOV/snubber protection. Compact design for distributed I/O applications.
TECHNICAL DATA
| Brand | GE/Emerson |
| Model | IC200MDL331 |
| Series | Versamax |
| Output Points | 8 isolated |
| Voltage | 120V AC |
| Current Capacity | 2A/point (20A inrush) |
| Isolation Rating | 1500V AC |
INSTALLATION GUIDE
- Requires external 85-132V AC power supply
- Snap into Versamax I/O carriers
- Max voltage drop: 2V
- Connect relays/solenoids directly
- Backplane power: 85mA @5V DC
DIAGNOSTICS & MAINTENANCE
- Monitor via 9 status LEDs (8 outputs + OK)
- Check leakage current: <2mA @132V AC
- Verify isolation annually: 1500V AC
- Test snubber/MOV protection
PACKAGING LIST
- IC200MDL331 Output Module
- Mounting accessories
- Installation guide
SHIPPING METHODS
Global express delivery via FedEx, UPS, DHL
FAQ
Q: What’s the maximum load per point?
A: 2A continuous (20A inrush).
Q: Are outputs electrically isolated?
A: Yes! 8 individually isolated channels.
Q: Protection against voltage spikes?
A: Built-in MOV/snubber circuits per output.
