Emerson IC200MDL632 VersaMax 16-Point DC Input Module
Product Description
This high-isolation DC input module (formerly GE Fanuc) features 16 individually isolated channels for 0-150VDC signals. Supports both positive and negative logic with 0.5ms response time. Ideal for critical control systems requiring fault-tolerant operation.
Technical Data
- Brand: Emerson Automation (formerly GE Intelligent Platforms)
- Model: IC200MDL632 (VersaMax Series)
- Inputs: 16 isolated channels
- Voltage Range: 0-150VDC
- Nominal Voltage: 125VDC
- Input Current: 1.7mA @125VDC, 2.2mA @150VDC
- Response Time: 0.5ms max
- Isolation:
- 250VAC continuous
- 1500VAC for 1 minute
Installation Guide
- Mount in VersaMax rack (no external power needed)
- Wire devices using positive/negative logic as required
- Set filter time via DIP switches (default=1ms)
- Verify green OK LED illuminates
Packaging & Shipping
- Includes: IC200MDL632 module, terminal block
- Shipping: FedEx, UPS, DHL (3-5 business days)
- Note: No additional filters required
FAQs
Q: Positive vs negative logic difference?
A: Positive: Current flows from device to module. Negative: Reverse flow.
Q: Can channels mix logic types?
A: Yes – each channel configurable independently.
Q: Minimum operating voltage?
A: Recognizes signals down to 5VDC (consult manual).
Q: Replacement for GE versions?
A: Fully compatible – identical specifications under Emerson.
