GE Fanuc IC693ALG390 ±10V Analog Output Module (Discontinued)
Product Description
This 2-channel analog output module for GE Series 90-30 PLCs delivers ±10V DC precision signals. Designed for closed-loop control systems, it drives instruments and data loggers with 2.5mV resolution. Note: Discontinued product – available for legacy system support.
Technical Data
- Brand: GE Fanuc
- Model: IC693ALG390 (Series 90-30)
- Lifecycle Status: Discontinued/Obsolete
- Output Range: -10 to +10V DC
- Channels: 2 isolated
- Resolution: 2.5 mV (1 LSB)
- Accuracy: ±5 mV @ 25°C
- Update Rate: 5 ms per channel
- Isolation: 1500V RMS (field-logic)
- Power: 18-30V DC external (24V nominal)
Installation Guide
- Mount in Series 90-30 rack
- Set DEF0 jumper: Hold-last-state or 0V default
- Connect shielded cables (ground shield to GND)
- Supply 24V DC (external or backplane)
Configuration Notes
- Stop/RESET mode: Choose 0V output or hold last value
- External power enables standby output retention
- Max 10% voltage ripple on power supply
Packaging & Shipping
- Includes: IC693ALG390 module
- Shipping: FedEx, UPS, DHL (3-5 business days)
- Note: No software included
FAQs
Q: Is this module still supported?
A: Discontinued – sold for legacy system maintenance only.
Q: Can it output current signals?
A: No – voltage output only (±10V range).
Q: How to configure stop behavior?
A: Set DEF0 jumper on terminal block (hold/0V).
Q: Replacement available?
A: Check GE’s migration guides for modern alternatives.
0.0 Average Rating Rated (0 Reviews)
