IC693MDL230 GE Fanuc – Isolated Input Module Series 90-30

Description

GE Fanuc IC693MDL230: Isolated AC Input Module

8-point 120V AC input module for Series 90-30 PLC systems. Built with 1500V isolation and reactive inputs to handle switches/sensors in harsh industrial environments.

TECHNICAL DATA

• Brand: GE Intelligent Platforms/GE Fanuc
• Model: IC693MDL230 (Series 90-30)
• Input Points: 8 points (1 common terminal)
• Voltage: 120V AC | Frequency: 50/60 Hz
• Input Current: 14.5 mA/point
• Isolation: 1500V RMS (field-to-logic)
• LED Indicators: 8 status LEDs (green=ON, red=fault)
• Power: AC only | DC not supported

INSTALLATION GUIDE

1. Power OFF PLC system
2. Mount in any Series 90-30 I/O slot
3. Connect external 120V AC power to common terminal
4. Wire devices (switches/sensors) to input points
5. Close hinged door with ID card for circuit labeling

COMPATIBILITY

Works with all GE Series 90-30 PLCs. Not compatible with Series 90-70 or DC-based systems.

PACKAGING LIST

• 1 × IC693MDL230 Module
• 1 × Hinged door with ID card
• Quick start guide

Warranty: 12 months from delivery

SHIPPING

FedEx | UPS | DHL (Global 3-6 business days)

FAQ

Q: Can it use DC power?
A: No. Requires 120V AC external supply.

Q: What devices connect to inputs?
A: Pushbuttons, limit switches, proximity sensors.

Q: How to identify faults?
A: LEDs turn red during system errors.

Q: Is the door card replaceable?
A: Yes. Slips out for circuit labeling.
