Description
GE Fanuc Strain Gauge Input Module
⚡ IC695ALG412 12-CHANNEL ISOLATED INPUT | 32-BIT PRECISION | INDUSTRIAL TOUGH
???? MODEL HIGHLIGHTS
- Channels: 12 Isolated Inputs
- Thermocouples: J/K/T/E/R/S/B/N/C
- Input Range: ±150mV to ±50mV
- Resolution: 32-bit Floating Point
- Accuracy: ±0.1% @25°C
????️ SAFETY & CERTIFICATIONS
- ✔ 250VAC Continuous Isolation
- ✔ 1500VAC/1min & 2550VDC/1sec Tested
- ✔ Open Wire/Short Circuit Diagnostics
- ✔ UL Class 1 Div 2 Compliant
⚙️ TECHNICAL EDGE
- ▸ Sigma-Delta A/D Conversion (15-120ms)
- ▸ 10dB Noise Rejection Improvement
- ▸ 500kΩ Input Impedance
- ▸ Configurable Update Rate: 15ms-120ms
???? INDUSTRY APPLICATIONS
→ Oil Refinery Process Monitoring
→ Power Plant Temperature Control
→ Pharmaceutical Batch Systems
→ Steel Mill Strain Measurement
→ Aerospace Component Testing
→ Food Production Sensors
→ Power Plant Temperature Control
→ Pharmaceutical Batch Systems
→ Steel Mill Strain Measurement
→ Aerospace Component Testing
→ Food Production Sensors
???? INSTALLATION GUIDE
- ▸ RTB Required: IC694TBBx32/TBSx32
- ▸ Power: 5V/425mA + 3.3V/400mA
- ▸ Temp Range: 0°C to +60°C (Operational)
- ▸ Vibration: 1.0G @57-500Hz
???? PACKAGE INCLUDES
- ▸ IC695ALG412 Module
- ▸ Terminal Block (Sold Separately)
- ▸ 12-Month Warranty
???? GLOBAL SHIPPING
FedEx | UPS | DHL
Delivery: 3-5 Business Days
