IC697MDL651 5V DC Input Module
DESCRIPTION
GE Fanuc’s IC697MDL651 delivers 32-point TTL-compatible DC input for Series 90-70 PLCs. Features selectable 1ms/10ms filtering and 1500V isolation. Ideal for high-speed industrial automation with 30m cable range.
TECHNICAL DATA
| Brand | GE Fanuc |
| Model | IC697MDL651 |
| Series | Series 90-70 |
| Input Points | 32 |
| Voltage | 5V DC |
| Input Range | -3 to 7V DC |
| Backplane Power | 0.53A @ 5V DC |
| Cable Length | 30m (98.4 ft) |
INSTALLATION GUIDE
- Use shielded cables for noise reduction
- Max distance: 30 meters
- Configure via Ethernet TCP/IP or SNP port
- Select 1ms or 10ms filtering in software
DIAGNOSTICS & MAINTENANCE
- Monitor via per-point LED indicators
- Verify ON-state current: 1.7mA (typical)
- Check OFF-state leakage: ≤1.1mA
- Test isolation voltage annually
PACKAGING LIST
- IC697MDL651 Input Module
- Terminal connectors
SHIPPING METHODS
Fast global delivery via FedEx, UPS, DHL
FAQ
Q: What filtering options are available?
A: 1ms or 10ms selectable via software.
Q: Maximum cable length supported?
A: Up to 30 meters (98.4 ft) for reliable operation.
Q: Compatible with TTL devices?
A: Yes. Designed for TTL-level inputs.
