Description
Product Overview
- T8310 is an Expander Processor from ICS Triplex.
- It sits in the two leftmost processor slots of the expander chassis.
- This module connects the expander and controller chassis.
- It uses fault-tolerant HIFT TMR architecture for high reliability.
Key Features
- Function
- Provides interface between expander and controller chassis.
- Diagnostics
- Fast fault identification with built-in self tests.
- Standby Support
- Supports auto and manual repair with standby module.
- Data Transfer
- Runs at 250 Mbps for fast communication.
- Power Supply
- Powered by dual redundant +24V DC from backplane.
Technical Specifications
- Model: T8310
- Part Number: T8310
- Manufacturer: ICS Triplex
- Type: Expander Processor
- Supply Ratings: 20 – 32 Vdc, 45 W
- Certifications: Ord / HazLoc / ATEX / IECEx
- Weight: 1.33 kg (2.93 lbs)
- Connection Cable: TC-301 communications cable
- Adapter: T8312 expander interface adapter
LED Indicators
- Healthy (3 LEDs)
- Green = healthy / Red = fault
- Active/Standby
- Green = active mode / Steady green = standby mode
- TxRx (3 LEDs)
- Green = receive
- Red = transmit
- Amber = both
- Off = no activity or failure
Installation & Connection
- Mount in the two leftmost processor slots of expander chassis.
- Use TC-301 hot link cable for connection.
- Connect to T8312 expander interface adapter.
- Power comes from dual redundant +24V DC backplane.
- No external power wiring needed.
Frequently Asked Questions (FAQ)
- What is HIFT TMR architecture?
- It stands for High Integrity Fault Tolerant Triple Modular Redundancy.
- This design keeps your system running even if one part fails.
- Can T8310 work without T8312 adapter?
- No. You need the T8312 expander interface adapter.
- The TC-301 cable connects both parts.
- What happens if one power supply fails?
- The second +24V DC supply takes over at once.
- Your system keeps working with no stop.
- How do I know if the module is faulty?
- Check the three Healthy LEDs.
- Red light means a fault. Green means all good.
- Is this module hot-swappable?
- Yes, with standby module configuration.
- You can replace it without powering down.
Experience-based Q&A & Selection Guide
- Field story: My system shows TxRx LED off. What to do?
- Check the TC-301 cable connection first.
- Then verify power to both chassis.
- Replace cable if still no light.
- Why choose T8310 over other expander processors?
- It gives true TMR fault tolerance at 250 Mbps speed.
- ICS Triplex is known for safety system reliability.
- Selection guide for expander processors
- Step 1: Check your chassis type – T8310 fits ICS Triplex expander.
- Step 2: Need TMR? Yes → T8310 is your choice.
- Step 3: Verify power – needs 20-32 Vdc dual supply.
- Step 4: Order T8312 adapter and TC-301 cable together.
- Pro tip: Buy a standby unit for zero downtime.
- What warranty comes with T8310?
- 12 months from shipment date.
- Covers all manufacturing defects.
- Which shipping options do you offer?
- FedEx – 3-5 business days
- UPS – Worldwide tracking included
- DHL – Express door to door
Ordering & Contact
- Model: T8310 Expander Processor
- Part Number: T8310
