Description
Bently Nevada 3300 XL 8 mm Proximity Probe
330103-01-08-10-02-00 by Bently Nevada is a high-performance sensor designed for vibration and position monitoring in industrial machinery. Featuring an M10x1 thread, PPS probe tip, and stainless steel case, this probe ensures durability and precision in harsh environments. Ideal for applications requiring reliable gap measurement and radial vibration analysis.
Technical Data
- Brand: Bently Nevada
- Model: 330103-01-08-10-02-00
- Suffix Breakdown: Unthreaded Length (01=10mm), Case Length (08=80mm), Total Length (10=1.0m), Connector (02=ClickLoc), Agency (00=None)
- Range: 2 mm (80 mils) linear range; starts at 0.25 mm (10 mils)
- Accuracy: Probe resistance 7.59Ω ±0.50 at 1.0m
- Output Signal: -1 to -17 Vdc (Recommended gap: -9 Vdc / 1.27 mm)
- Operating Temperature: -52°C to +177°C (Standard); Extended: Tip up to +218°C, Cable up to +260°C
- Cable: 1.0m standard; supports up to 305m (1000ft) with shielded triad cable
Installation Guide
- Use 0.2–1.5 mm² (16–24 AWG) shielded triad cable for field wiring.
- Max thread engagement: 15mm for M10x1.
- Avoid temperatures below -34°C to prevent seal damage.
Certifications
- ATEX/IECEx: AEx/Ex ia IIC T5-T1 Ga (Zone 0); AEx/Ex nA/ec IIC T5-T1 Gc (Zone 2)
- Compliant with IEC 68-2-3 humidity standards.
Applications
Used in gas turbines, compressors, and pumps for vibration monitoring. Ensures predictive maintenance in oil & gas, power generation, and heavy industries.
Contact: sales@ubestplc.com for quotes or technical support.
Explore more detailed information in official datasheet here: 3300 XL 8 mm Proximity Transducer System Datasheet
