Description
Product Overview
The Leuze K-D M12W-4P-2m-PVC cable offers safe links for sensors and field devices. It gives stable contact and strong pull strength. It fits tight spaces with its angled plug. And it works well in harsh sites with dust and heat. It gives long life and simple setup.
Structured Type Code
- K-D
- K-D connection cable
- M12W
- M12 connector
- W = angle form
- 4P
- 4 pins
- 2m
- 2-meter cable length
- PVC
- PVC outer material
Electrical Data
- Voltage for M12: up to 250 VAC/DC (3/4-pin)
- Voltage for M12: up to 125 VAC/DC (5-pin)
- Voltage for M8: up to 60 VAC/DC
- Current: up to 4A per pin
- Insulation grade: Category I per IEC 60664-1
- Low loss along full cable length
- Stable signal in heavy noise zones
Mechanical Data
- Connector shell: diecast zinc, nickel-plated
- Torque: 0.6 Nm, self-locking
- Cable sheath: PVC, black color
- Grip: TPU for strong hold
- Conductor size: 0.34 mm² for M12
- Diameter: 4.7 to 5.7 mm
- Bending radius: at least 10× cable diameter
- Pull strength fit for moving parts
Environmental Data
- Fixed wiring: -30°C to +70°C
- Flexible wiring: -5°C to +70°C
- Good seal against dust
- Stable under vibration
- Strong UV resistance for outdoor use
Expanded Technical Highlights
- Low contact resistance for clean signals
- Quick link to sensors and I/O blocks
- Short plug-in time for field teams
- Good crush strength on factory floors
- Safe for long-term bending cycles
- Stable electrical path in high heat shops
Key Selling Points
- Simple use in tight machine areas
- Fast install with angle connector
- Smooth fit for Leuze sensors
- Long cable life under daily motion
- Clear marking for fast ID
- Strong shield against line noise
Warranty
- 12-month warranty
- Applies to normal industrial use
- Faults from misuse not covered
Shipping
- FedEx international
- UPS global
- DHL express
FAQ
- How can I stop connector wear?
- Keep torque near 0.6 Nm and avoid over-tightening.
- Can I use the cable near motors?
- Yes, but route the line away from strong magnetic fields.
- How do I confirm pin order?
- Check the marking on the plug before wiring the device.
- Is the cable safe for fast-moving parts?
- Yes. The PVC jacket supports long flex cycles when routed correctly.
- What should I do if the signal drops?
- Clean the connector pins and check if the bend radius is too tight.
