Product Overview
The Bently Nevada 125840-02 Low Voltage AC Power Input Module is a specialized component for the 3500 series monitoring systems, designed to convert 110VAC input to stable DC power for industrial applications. With hazardous area certifications and robust environmental tolerance, it ensures reliable performance in demanding conditions.
Technical Specifications
- Part Number: 125840-02
- Input Voltage:
- 85–132VAC RMS (47–63Hz)
- Peak Range: 120–188VAC
- Efficiency: Optimized for low-voltage conversion
Certifications & Compliance
| Standard | Details |
|---|---|
| EMC | EN 61000-6-2 (Immunity) EN 61000-6-4 (Emissions) |
| Safety | EN 61010-1 Compliant |
| Hazardous Areas | CSA Class I Div 2 (A-D) ATEX/IECEx II 3G Ex nA nC ic IIC T4 Gc |
Environmental Ratings
- Operating Temp: -30°C to +65°C
- Storage Temp: -40°C to +85°C
- Humidity: 95% non-condensing
Physical Specifications
- Dimensions: 120.7mm × 25.4mm × 114.3mm (4.75″×1″×4.5″)
- Weight: 0.34 kg (0.75 lb)
- Mounting: 3500 system backplane integration
Industrial Applications
- Chemical Plants: Power supply for monitoring systems in Zone 2 areas
- Power Distribution: Substation equipment monitoring
- Manufacturing: Motor control center installations
Compliance Support: Contact sales@ubestplc.com
