MTL Hazardous Area Controller MTL5024 | Buy Now

Description

MTL5024: Explosive-Zone Control Master

Command hazardous devices from safety! The MTL5024 barrier drives solenoids, alarms, and LEDs in explosive areas using simple switches or logic signals. Phase reversal option included. Zone 0 certified.

⚡ Control Superpowers

• Drives solenoids, alarms, LEDs in danger zones
• Works with switches or logic signals
• Instant phase reversal option
• Dual LED health monitoring

???? Performance Specs

• Input: Switch contacts or logic signals
• Output Voltage: 12.85-25V
• Output Current: 45mA max
• Control Logic: ON <1.4V / OFF >4.5V
• Power: 20-35V DC (75-120mA)
• Isolation: 1500V AC protection
• Response: <10ms switching
• Temp Range: -20°C to +70°C
• Safety: 25V, 170Ω, 147mA

???? Connection Guide

• 1,2: Hazard Output (-/+)
• 3: Earth Leakage Detect
• 11,12: Control Signal (-/+)
• 13,14: DC Power (-/+)

????️ Zero-Risk Package

• 12-month full protection warranty
• Global express: Fedex, UPS, DHL
• Dual LED instant diagnostics

???? Control Secrets

Q1: What devices can MTL5024 drive?
A: Solenoids, alarms, LEDs – any IS/non-energy-storing apparatus.

Q2: How does phase reversal work?
A: Flip a switch to change ON/OFF signal behavior.

Q3: What’s special about terminal 3?
A: Earth leakage detection for extra safety.

Q4: What logic levels trigger it?
A: <1.4V = ON, >4.5V = OFF. Simple!

Q5: How much current can it deliver?
A: 45mA maximum to hazardous-area devices.
