Description
MTL3046B: Smart Transmitter Interface for Hazardous Areas
The MTL3046B safely powers and communicates with smart transmitters in explosive areas. It provides 15V at 20mA to run your device. It also repeats the 4-20mA signal perfectly for your safe-area systems. You can calibrate and test transmitters from your computer. It works with most smart transmitters available today.
Technical Details
Brand: MTL
Model: 3046B
Input/Output Signal: 4-20mA with digital communication
Transmitter Power: 15V minimum at 20mA (28V max open circuit)
Line Resistance: [(15V – transmitter need) x 50] Ω
Digital Bandwidth (to field): 10Hz to 8kHz
Digital Bandwidth (to safe area): DC to 10kHz
Load Resistance: 20 to 750Ω (250Ω for digital)
Accuracy: Better than 20μA at 20°C
Temperature Drift: <1μA/°C
Response Time: 40μs to within 10%
Supply Voltage: 20-35V DC
Current Use: 85mA typical at 24V
Power Use: 1.7W typical at 24V
Hazardous Rating: Zone 0, IIC, T4-T6 / Div 1, Group A
Safety: Um=250V, Voc=28V, Isc=93mA
Unit Weight: 170g
Package Includes
1 x MTL3046B interface unit. Shipped quickly via FedEx, UPS, or DHL.
Quality Promise
12-month warranty against defects. Reliable performance guaranteed.
Expert Questions Answered
- Can I use it with regular 4-20mA transmitters?
Yes, the MTL3046B works with both smart and standard analog transmitters. - What communication protocols does it support?
It supports HART and other digital signals superimposed on 4-20mA. - How much voltage does it provide to transmitters?
It provides a minimum of 15V at 20mA, with a maximum open circuit voltage of 28V. - Can I connect a handheld communicator?
Yes, you can connect a communicator in either the safe or hazardous area. - What is the digital signal bandwidth?
From field to safe area: DC to 10kHz. From safe area to field: 10Hz to 8kHz.
