Description
MTL3052 Digital Signal Isolator: Safe Data Transfer for Hazardous Areas
The MTL3052 is a high-speed isolator designed for digital signals. It protects data highways in MTL800 Series systems. It offers two output choices for different needs. Perfect for use in dangerous areas where safety is critical.
Technical Specifications
Brand & Model: MTL MTL3052 Digital Isolator
Input Voltage: 4 to 12V DC
Signal Bandwidth: DC to 10kHz
Output Option 1: 15V, 100Ω, 150mA
Output Option 2: 15V, 180Ω, 83.3mA
Power Dissipation: 160mW max
Hazardous Location Rating: Zone 0, IIC, T4-T6 / Div 1, Group A
Operating Temperature: -20°C to +70°C
Storage Temperature: -40°C to +85°C
Isolation Voltage: 250V rms
What You Get
One MTL3052 unit, documentation, and a 50mA replacement fuse. Shipped fast via FedEx, UPS, or DHL.
Your Guarantee
We stand behind our products. Enjoy a 12-month warranty for guaranteed quality.
