Allen-Bradley 1769-L36ERM CompactLogix Programmable Automation Controller

The Allen-Bradley 1769-L36ERM is a powerful and versatile Programmable Automation Controller (PAC) from Rockwell Automation’s CompactLogix 5370 series. It efficiently handles complex control, motion, and communication tasks across various industrial applications.

Key Technical Specifications

• Brand & Manufacturer: Allen-Bradley / Rockwell Automation
• Model Number: 1769-L36ERM
• Controller Memory: 3 MB user memory
• Non-Volatile Memory: Ships with a 1 GB 1784-SD1 card; upgradeable to a 2 GB 1784-SD2 card
• Communication Ports: Two (2) embedded Ethernet/IP ports and One (1) USB programming port
• Integrated Motion: Supports control for up to 16 axes over EtherNet/IP
• Local I/O Capacity: Supports up to 30 1769 Compact I/O modules across 3 expansion banks
• Operating Temperature: 0° to 60°C (32° to 140°F)
• Vibration Resistance: Operational at 5G from 10-500 Hz
• Shock Rating: Withstands 20G shock during operation
• Mounting: DIN rail or panel mounting
• Wire Requirements: Accepts 22-14 AWG solid or 22-16 AWG stranded copper wire at 90°C
• Power Supply Distance: Must be installed within 4 modules of the power supply

Programming & Software

• Program the 1769-L36ERM using Studio 5000 Logix Designer software (v21.xx and later).
• It supports all IEC 61131-3 standard languages for maximum flexibility.
• Choose from Relay Ladder Logic, Structured Text, Function Block Diagram, and Sequential Function Chart (SFC).

Packaging & Shipping

• The package includes one 1769-L36ERM controller and one 1 GB 1784-SD1 memory card.
• We ship globally via reliable couriers like FedEx, UPS, and DHL.
• The unit ships in a box with dimensions of 8 x 8 x 5 inches and a weight of 2 pounds.

Comparison With Related Products

• 1769-ARM: This is an address reserve module, not a controller. It is used to reserve space in a chassis.
• 1769-CRL3: This is an expansion cable used to connect additional I/O banks to a CompactLogix controller.

Frequently Asked Questions (FAQ)

• How many axes of motion can this controller handle?
• It supports up to 16 axes over EtherNet/IP.
• What memory card does it use?
• It uses a standard 1784-SD1 or 1784-SD2 card for non-volatile storage.
• What software is needed for programming?
• You need Rockwell Automation’s Studio 5000 Logix Designer.
• Can it communicate with third-party devices?
• Yes, its EtherNet/IP ports enable communication with many third-party devices.
