Premium Bently Nevada 330707-00-20-90-11-05 Probe | 9m FluidLoc & Certified

Description

The Ultimate Industrial Vibration Probe

Introducing the premium Bently Nevada 3300 XL 11 mm Proximity Probes for critical applications. Model 330707-00-20-90-11-05 is the top-tier choice, combining maximum cable length, environmental sealing, and hazardous area certification. It’s engineered for reliability in the toughest conditions like offshore platforms and chemical processing plants.

Premium Feature Set

• Dual Protection: FluidLoc cable AND multiple hazardous area approvals.
• Maximum Reach: 9.0-meter integrated cable for remote installations.
• Connector Safety: Includes a protective cover for the ClickLoc connector.
• Heavy-Duty Build: 2.0-inch case with 5/8-18 UNF industrial thread.
• Extreme Environment Ready: Performs from -51°C to +177°C.

Complete Model Analysis: 330707-00-20-90-11-05

• Product Foundation: 330707 Series (11mm, 5/8-18 UNF, No Armor)
• Full Specification Breakdown:
  • Code Block 1 [-00]: Body Profile
    • Meaning: 0 inches unthreaded. Standard fully-threaded body.
  • Code Block 2 [-20]: Case Length
    • Meaning: 2.0-inch long case. The most common and versatile length.
  • Code Block 3 [-90]: Integrated Wiring Solution
    • Meaning: 9.0-meter permanently attached cable. Eliminates need for long extensions.
  • Code Block 4 [-11]: Connection & Environmental Guard
    • Meaning: ClickLoc connector with protector AND FluidLoc cable. Superior moisture/contaminant defense.
  • Code Block 5 [-05]: Compliance Certification
    • Meaning: Multiple Agency Approvals. Certified for explosive atmospheres (e.g., ATEX, IECEx).

Technical Data

• Electrical Performance:
  • DC Resistance (9m System): 8.5 Ω ± 1.1 Ω
  • Cable: 75 Ω Triaxial, FEP Insulated, FluidLoc Jacket
• Installation Parameters:
  • Mounting Thread: 5/8-18 UNF
  • Torque Setting: 15.2 N•m recommended (133 in•lb)
  • Maximum Torque: 45.2 N•m absolute maximum
  • Cable Handling: Minimum bend radius of 1.0 inch (25.4 mm)
• Material & Build:
  • Housing: 304 Stainless Steel
  • Tip: Durable PPS Plastic
  • Seals: High-temperature Viton O-ring

Ordering & Guarantee

• Included: One probe (9m FluidLoc cable, connector protector).
• Warranty: Full 12-month warranty against defects.
• Global Logistics: Express shipping via FedEx, UPS, DHL available.
• Expert Assistance: Contact: +86 158 8020 0923 (WhatsApp)

Frequently Asked Questions

Product Superiority

• Q: What makes the 330707-00-20-90-11-05 the most advanced 11mm probe option?
• A: It uniquely combines three critical features: the longest 9m cable, FluidLoc moisture protection, and hazardous area certification. This makes it suitable for the most demanding, safety-critical, and remote installations.

Application & Specifications

• Q: Is this probe suitable for offshore oil and gas platforms?
• A> Yes. The 330707-00-20-90-11-05 is ideal for offshore use. Its FluidLoc cable resists salt spray and humidity, while its multiple approvals meet the strict safety standards required in offshore hazardous zones.
• Q: What is the advantage of having both a connector protector and FluidLoc cable?
• A> The connector protector shields the electrical pins from physical damage during storage and handling. The FluidLoc cable prevents moisture ingress along the cable itself. Together, they provide comprehensive protection from installation through operation.

Purchasing & Service

• Q: Why is this model more specialized than a standard probe?
• A: Its combination of features targets specific, high-stakes industries. The certifications and FluidLoc design add cost but are mandatory for compliance and reliability in regulated, wet, or remote environments.
• Q: Can you provide the certification documents with the probe?
• A> Yes. For certified models like the 330707-00-20-90-11-05, we can provide the necessary documentation (e.g., ATEX Certificate) to support your plant’s safety file and compliance audits.

Selection Guide for Professionals

• Step 1: Your application is in a classified hazardous area requiring certified equipment.
• Step 2: The environment is wet, humid, or exposed to chemicals (requires FluidLoc).
• Step 3: The monitoring panel is far from the machine (requires 9m cable).
• Step 4: Your mounting hole is 5/8-18 UNF.
• Step 5: Select 330707-00-20-90-11-05 – the solution that meets all these criteria.
• Confirm Your Needs: Talk to an application specialist: +86 158 8020 0923.
