Description
Product Overview
Brand: Rockwell Automation
Manufacturer: Allen-Bradley
Series: ETAP
Model: 1783-ETAP2F
The 1783-ETAP2F EtherNet/IP Tap links devices into ring networks.
It supports stable data flow with low power use.
The design fits harsh factory floors.
The unit helps reduce network downtime.
Key Selling Points
- Fast fault detection improves uptime
- Compact housing saves panel space
- Low power draw reduces heat
- Clear LED status speeds troubleshooting
- Industrial-grade build ensures long life
Network Performance
- Network Type: EtherNet/IP
- Connector: RJ45, IEC 60603-7
- Speed Support: 10 Mbps and 100 Mbps
- Duplex Mode: Full and half duplex
- Topology: Ring network support
Power & Electrical Data
- Rated Voltage: 24 V DC
- Voltage Range: 20.4 to 27.6 V DC
- Max Power Use: 6.24 W
- Max Current: 260 mA
- Connection Torque: 0.6 to 0.8 N·m
Cable & Wiring Requirements
- Cat 5e cable per TIA 568-B.1
- Cat 5 cable per ISO/IEC 24702
- Single wire: 0.33 to 3.3 mm²
- Dual wire: up to 1.3 mm² solid
- Copper wire rated 75°C or higher
Status & Diagnostics
- OK LED shows power and system health
- LINK LEDs display speed and activity
- Color change shows network faults
- Flashing signals update or recovery states
Environmental Limits
- Operating Range: -25°C to +60°C
- Max Air Temperature: 60°C
- Designed for industrial cabinets
Installation Notes
- Mount inside control panels
- Allow airflow around the unit
- Check torque after wiring
- Verify LED status at startup
Typical Applications
- Device-level ring networks
- Machine automation lines
- Packaging systems
- Process control skids
Package Contents
- 1 × Allen-Bradley 1783-ETAP2F
- Product identification label
Warranty & Logistics
- Warranty: 12 months
- Courier: FedEx, UPS, DHL
FAQ
- What is a good use case for this tap?
- It fits ring networks that need fast fault isolation.
- Does this unit support mixed network speeds?
- Yes. It handles both 10 Mbps and 100 Mbps devices.
- How can LED colors help maintenance?
- They show link speed, activity, and fault status.
- Is low power important in control cabinets?
- Yes. It reduces heat and extends component life.
- How do I choose between ETAP models?
- Select based on port count and ring role needs.
