Description
Product Description
- Allen-Bradley 1783-US6T2F is a managed industrial Ethernet switch.
- It belongs to the Stratix 2000 family by Rockwell Automation.
- The design supports stable control networks in harsh environments.
- Eight total ports ensure flexible device connections.
- It supports copper and fiber communication in one compact unit.
- Managed features improve diagnostics and network visibility.
Key Value Highlights
- Industrial reliability for automation systems.
- Mixed media support reduces wiring limits.
- Wide power range simplifies panel design.
- Compact enclosure saves cabinet space.
Technical Specifications
- Brand: Allen-Bradley / Rockwell Automation
- Model: 1783-US6T2F
- Series: Stratix 2000
- Product type: Managed Ethernet switch
- Total ports: 8 ports
- Copper ports: 6 RJ45 Fast Ethernet
- Fiber ports: 2 SFP multimode modules preinstalled
- Data rate: 10 / 100 / 1000 Mbps
- Supply voltage: 12–48 VDC or 18–30 VAC
- Nominal voltage: 24 VAC / VDC
- Frequency: 50 / 60 Hz
- Power input: SELV rated
- Nominal current: DC 250 mA, AC 500 mA
- Maximum current: DC 510 mA, AC 1100 mA
- Inrush current: 0.41 A max
- Power dissipation: 5.927 W
- Maximum consumption: 4.6 W
Environmental & Reliability Data
- Operating temperature: -10°C to +60°C
- Maximum ambient air temperature: 60°C
- Operating shock resistance: 15 g
- Designed for industrial vibration conditions
- Strong noise immunity for factory floors
Mechanical Information
- Enclosure dimensions: 114.5 × 76.8 × 45.6 mm
- Compact housing fits dense control panels
Installation Guide
- Mount securely inside a grounded enclosure.
- Ensure airflow around the device.
- Use regulated power within rated limits.
- Verify fiber type before SFP connection.
Commissioning & Maintenance
- Managed interface simplifies network setup.
- Status LEDs support fast fault location.
- No frequent calibration required.
- Firmware updates improve long-term stability.
Compatibility
- Works with Allen-Bradley PLC networks.
- Supports standard industrial Ethernet protocols.
- Compatible with copper and multimode fiber cabling.
Diagnostics & Network Visibility
- Managed switching enables traffic monitoring.
- Port status shows link and activity.
- Helps reduce downtime during faults.
Typical Applications
- Factory automation networks
- Process control systems
- Packaging and material handling
- Energy and utility infrastructure
Certifications & Compliance
- Industrial-grade design standards
- Complies with relevant safety requirements
Packing List
- 1 × 1783-US6T2F Ethernet switch
- Preinstalled fiber SFP modules
- Factory packaging
Warranty & Logistics
- 12-month warranty
- Shipping via FedEx, UPS, or DHL
- Secure industrial packaging
FAQ
- Is this switch suitable for harsh environments?
- Yes. It supports high temperature and shock resistance.
- Can it mix copper and fiber links?
- Yes. It supports both media at the same time.
- Does it need frequent maintenance?
- No. Basic visual checks are enough.
- What is a common field tip?
- Label ports clearly during installation.
Selection Guidance
- Choose this model for mixed copper and fiber needs.
- Ideal for managed industrial Ethernet networks.
- Consider port count and temperature limits.
