S30A-7111CP SICK Safety Scanner – Buy S3000 PROFINET Device

Description

Product Overview

SICK S30A-7111CP is a safety laser scanner from the S3000 PROFINET IO Advanced family. It comes as a sensor head with I/O module. This device monitors hazardous areas indoors. It connects directly to PROFINET networks with PROFIsafe.

Key Benefits

• PROFINET IO with PROFIsafe – no local I/O needed
• Very wide 190° scanning angle
• 7 meter protective field for machine guarding
• 49 meter warning field and distance measurement
• Laser Class 1 – safe for eyes
• IP65 rated aluminum housing

Technical Specifications

• Brand: SICK Sensors
• Model Number: S30A-7111CP
• Series: S3000 PROFINET IO Advanced
• Product Type: Safety laser scanner with I/O module
• Application: Indoor only
• Scanning angle: 190°
• Response time: 60 ms
• Weight: 3.3 kg

Order Code – Tree Structure

• S30A = S3000 family (Advanced)
• 7 = 7m protective field range
• 111 = Device configuration code
• CP = PROFINET IO with PROFIsafe

Range & Field Data

• Protective field range: 7 meters
• Warning field range: 49 meters (20m at 20% reflectivity)
• Distance measuring range: 49 meters
• Protective field supplement: 100 mm
• Number of fields: 8 total
• Number of field sets: 4
• Dual field sets: Yes
• Monitoring cases: 4

Resolution & Accuracy

• Configurable resolution: 30, 40, 50, 70, or 150 mm
• Angular resolution: 0.5° or 0.25° (depends on range)
• Multiple sampling: 2 to 16 times (configurable)
• Auto reset delay: 120 ms to 4,920 ms

Safety Ratings – Certified Protection

• Type: Type 3 (IEC 61496)
• SIL: SIL 2 (IEC 61508)
• Category: Category 3 (EN ISO 13849)
• Performance Level: PL d (EN ISO 13849)
• PFHD: 8.0 x 10⁻⁸
• Mission Time (TM): 20 years
• Safe state on fault: Logic 0

PROFINET & Industrial Network

• Fieldbus: PROFINET PROFIsafe
• Integration: Integrated in device
• 2-port real-time switch per PROFINET V2.2
• PROFIsafe profile: 6-byte input + 6-byte output
• Cycle time options: 4, 8, 16, 32 ms
• GSDML: Per V2.25 specification
• Conformance Class: Class B

Connections & Interfaces

• Bus connection: Two RJ-45 push-pull female connectors
• Supply connection: System plug (with or without cable)
• Configuration interface: RS-232 (9.6, 19.2, 38.4 kBaud)
• Ethernet ports: TCP port 9000, UDP port 30718

Switch & Network Features

• Auto-negotiation, Auto-crossover (MDIX), Auto-polarity
• 100Base-TX support
• MRP client support
• SNMP, MIB-2, LLDP (IEEE 802.1AB)
• Cable diagnostics and neighborhood alerts
• Port statistics and I&M 0 to 4

Electrical Data

• Protection class: III (VDE 0106, EN 60950)
• Supply voltage Vs: 24 V DC (16.8 to 28.8 V DC)
• Power consumption: 0.8 A at 24 V DC (no output load)

Mechanical & Housing

• Dimensions (W x H x D): 155 x 185 x 160 mm
• Housing material: Aluminum die cast, yellow (RAL 1021)
• Front screen: Polycarbonate with scratch-resistant coating
• Enclosure rating: IP65 (EN 60529)

Ambient Conditions

• Operating temperature: -10°C to +50°C
• Storage temperature: -25°C to +50°C
• Vibration resistance: Class 5M1 (IEC 60721-3-5)
• Shock resistance: 50 m/s², 11 ms; 100 m/s², 16 ms

Laser Data – Safe for Eyes

• Light type: Pulsed laser diode
• Wavelength: 905 nm
• Laser class: Class 1 (21 CFR 1040.10, IEC 60825-1)
• Detectable remission: 1.8% to over 1,000% (reflectors)

Installation Guide

• Mount indoors only (no outdoor use)
• Keep front screen clean for best detection
• Connect 24V DC power (Class 2 supply recommended)
• Use RJ-45 push-pull connectors for PROFINET
• Configure field sets using SOPAS software (RS-232)
• Add system plug with or without connecting cable

Setup & Commissioning

• Use SOPAS ET configuration software via RS-232
• Import GSDML file into your PROFINET controller
• Set PROFIsafe address and cycle time (4-32 ms)
• Configure up to 4 field sets with 8 total fields
• Test each protective field with test rod
• Check LED indicators after power-up

Diagnostics & Maintenance

• Application-specific channel diagnostics available
• Report system errors via PROFINET
• Cable diagnostics check Ethernet link health
• Clean front screen monthly – dust reduces range
• No moving parts inside the scanner

Compatibility

• Works with any PROFINET controller supporting PROFIsafe
• Supports Siemens, Rockwell, and other major PLCs
• GSDML file provided by SICK
• Requires external controller – no local outputs

Packing List

• 1x SICK S30A-7111CP laser scanner
• System plug (type depends on order)
• Documentation CD
• Original factory box
• Mounting accessories (sold separately in some kits)

Warranty & Shipping

• 12-month factory warranty
• Fast delivery: FedEx, UPS, DHL
• Tracking number for all orders

Typical Applications

• Mobile robot collision avoidance
• Automatic guided vehicle (AGV) safety
• Stationary machine hazardous area guarding
• Warehouse automation zone monitoring
• Palletizer and conveyor access protection

5 Professional FAQs

• Does this scanner work outdoors?
• No. This model is for indoor use only (IP65 but sunlight may interfere).
• Can I use this without a PROFINET controller?
• No. This device has no local outputs. You need a PROFINET controller with PROFIsafe.
• What is the minimum object size it can detect at 7m?
• At 30mm resolution (highest), it detects 30mm objects. At 150mm resolution, larger objects only.
• Do I need to buy the system plug separately?
• Please check your order. Some kits include system plug. Contact us for confirmation.
• How do I change field sets during operation?
• Send PROFIsafe output data. The scanner switches field sets based on your PLC logic.

Selection Guide – Pick the Right S3000 Scanner

• Step 1 – Choose fieldbus: S30A-7111CP has PROFINET. For EtherCAT or Ethernet/IP, pick other models.
• Step 2 – Check protective range needed: 7m fits most indoor AGV and machine guarding. For 5.5m, choose S30A-6011CP.
• Step 3 – Resolution requirement: 30mm detects small parts. 150mm is for large pallets.
• Step 4 – Cycle time: 4ms for fast robots. 32ms for slower conveyors. Faster cycle reduces max range.
• Pro tip: For dirty environments like woodworking, add an air purge unit to keep front screen clean.
