Schneider Electric BMENOS0300C Modicon X80 – Ethernet Switch Module

Description

Industrial Ethernet Switch Module for Harsh Environments

The BMENOS0300C provides reliable network switching for industrial automation systems. This robust switch module connects devices using Ethernet/IP protocol. It ensures stable communication in challenging factory conditions.

Technical Specifications

• Brand: Schneider Electric
• Model: Modicon X80 BMENOS0300C
• Ethernet Ports: 3 ports for device networks
• Supply Voltage: 24V DC via backplane
• Power Consumption: 3.3W at 25°C, 4.5W at 60°C
• Operating Temperature: 0°C to 60°C industrial range
• Storage Temperature: -40°C to 85°C
• Protection Rating: IP20 with conformal coating
• Operating Altitude: Up to 2000 meters

Environmental Durability

• Gas Resistance: Class Gx ISA S71.04 compliant
• Dust Protection: Class 3S4 IEC 60721-3-3 rated
• Chemical Resistance: Conformal coating protection
• Hazardous Areas: ATEX Zone 2/22 certified
• Vibration/Shock: Industrial environment tested

Packaging & Shipping Details

• Unit Package: Individual protective packaging
• Package Dimensions: 12.2cm × 11.2cm × 5.8cm
• Unit Weight: 264 grams including packaging
• Bulk Package: 5 units per master carton
• Shipping Methods: FedEx, UPS, DHL available

Frequently Asked Questions

• What is the maximum operating temperature?
  The switch operates reliably from 0°C to 60°C.
• How many devices can connect to this switch?
  Three Ethernet/IP devices connect through the ports.
• What certifications does this module have?
  It carries ATEX, IECEx, UL, CSA, and CE certifications.
• Can it operate in high humidity areas?
  Yes, it handles 95% humidity without condensation.
• What power source does it require?
  It uses 24V DC power from the backplane.

Documentation & Support Services

• Includes 12-month product warranty coverage
• For technical Support, Inquiry, Contact: +86 158 8020 0923
• Expert installation support available
