Modicon M340 Compact Automation Processor
The BMXP3420102 delivers powerful control for medium-scale automation applications. This versatile processor handles up to 1024 discrete and 256 analog I/O points. It supports multiple communication protocols including Modbus and CANopen.
Technical Specifications
- Brand: Schneider Electric
- Model: Modicon M340 BMXP3420102
- I/O Capacity: 1024 discrete + 256 analog maximum
- Processing Speed: 6.4-8.1K instructions/ms
- Memory Capacity: 4MB internal RAM total
- Operating Temperature: 32°F to 140°F (0°C to 60°C)
- Power Consumption: 90mA at 24V DC
- Communication Ports: Serial, USB, CANopen
- Module Weight: 0.46 lb (0.21 kg)
Communication Capabilities
- Multi-protocol support: Modbus, CANopen, Serial
- CANopen master for up to 63 devices
- RS232 and RS485 serial communication
- USB programming port 12 Mbit/s
- 2 Ethernet communication modules
- 4 AS-Interface module support
Memory & Processing Features
- Program Memory: 3.5MB dedicated space
- Data Memory: 256KB internal storage
- Backup Storage: 8MB memory card included
- Task Management: 64 event tasks available
- Execution Speed: 0.12µs for Boolean operations
Environmental Specifications
- Protection Rating: IP20 standard enclosure
- Temperature Range: 0°C to 60°C operation
- Humidity Range: 10% to 95% non-condensing
- Hazardous Locations: Class I Division 2 rated
- Vibration/Shock: Industrial environment tested
Packaging & Delivery
- Unit Package: Individual protective box
- Package Dimensions: 4.88″ × 4.53″ × 2.13″
- Unit Weight: 8.783 oz (249g) packaged
- Bulk Package: 15 units per shipping carton
- Shipping Carriers: FedEx, UPS, DHL available
Installation Guidelines
- Install in Modicon M340 compatible racks
- Use internal backplane power supply
- Connect using shielded communication cables
- Monitor seven status LEDs for system health
- Follow all local electrical codes
Frequently Asked Questions
- What is the maximum CANopen network size?
The processor supports up to 63 CANopen devices. - How much program memory is available?
You get 3.5MB for program storage and constants. - What communication speeds are supported?
CANopen runs from 20 kbit/s to 1 Mbit/s. - Can this processor handle motion control?
Yes, it supports independent CANopen motion axes. - What backup storage is included?
An 8MB memory card comes with the processor.
