Description
Schneider Electric 140EHC20200 High-Speed Counter Module
The 140EHC20200 is a fast counter module for Modicon Quantum. It counts signals up to 500,000 times per second. This module has two counting channels. It also has four output switches. Get the full manual here: Download Manual Now.
Main Features
- Brand: Schneider Electric
- Model: 140EHC20200
- Two counting channels for dual measurements
- Very fast counting: 500 kHz maximum speed
- Works with encoder signals and pulse trains
- Four transistor outputs for control signals
- Each output can switch 0.5 Amps
Technical Details
- Needs 19-30V DC external power
- Uses 650 mA from the PLC rack
- Works from 0°C to 60°C (32°F to 140°F)
- Has protection against short circuits
- LED lights show channel status
- Fuse protection: 2.5 Amps per output
Shipping Info
- Box size: 12.6 x 6.7 x 2.0 inches
- Weight: 15.7 ounces (444 grams)
- We ship via FedEx, UPS, and DHL
- 12-month warranty included
- Product is returnable
Need help? Contact: +86 158 8020 0923 for support.
Questions & Answers
- What can I count with this module?
You can count encoder pulses, motor rotations, and production parts. - How fast can it count?
It counts up to 500,000 pulses per second. - What are the outputs for?
The outputs can control relays, lights, or small devices. - Does it need special power?
Yes, it needs 19-30V DC external power to work. - Is it easy to install?
Yes, it fits standard Quantum racks and is easy to set up.
