Schneider Electric Modicon Quantum 140CPS21100 Power Supply
This standalone power module delivers stable 5.1V DC power for your Modicon Quantum automation system. It ensures reliable operation in industrial environments.
Technical Specifications
- Brand: Schneider Electric
- Model: 140CPS21100
- Input Voltage: 24V DC (20-30V range)
- Input Current: 1600 mA maximum
- Output Voltage: 5.1V DC regulated
- Output Current: 0.3 to 3.0 A
- Operating Temperature: 0°C to 60°C
- Inrush Current: 30 A maximum
- Fuse Rating: 2.5 A slow-blow
- Weight: 0.65 kg (1.43 lb)
Installation Guide
- Use as standalone power supply unit
- Connect to 24V DC power source
- Ensure proper ventilation around unit
- Check polarity before connecting
- Verify input voltage matches specifications
Environmental Tolerance
- Works at heights up to 5000 meters
- Handles 95% humidity without condensation
- Resists electrostatic discharge up to 8kV
- Operates in electromagnetic fields up to 10V/m
- Storage temperature from -40°C to 85°C
Package Contents
- One 140CPS21100 power supply module
- Installation documentation
- Mounting hardware included
Shipping Information
- We ship worldwide via FedEx, UPS, DHL
- Package dimensions: 31.2 x 16.3 x 4.5 cm
- Package weight: 729 grams
Frequently Asked Questions
- What input voltage range does this unit accept?
The power supply accepts 20-30V DC input with 24V DC nominal rating. - How much output current can it provide?
It delivers 0.3 to 3.0 amps at 5.1V DC output voltage. - What protection features does it include?
The module has internal overload and overvoltage protection circuits. - What is the maximum operating altitude?
It operates reliably at heights up to 5000 meters above sea level. - What fuse should I use with this unit?
Use a 2.5 amp slow-blow fuse for proper circuit protection.
Documentation Download
- Get the complete technical manual here:
Download Modicon Quantum Power Supply Manual
For technical Support, Inquiry, Contact: +86 158 8020 0923
All products include 12-month warranty coverage for your peace of mind.
