Description
T8123 Trusted TMR Processor Interface Adapter
Connect external systems to a Trusted TMR Processor easily. This adapter mounts directly to the rear of the Controller Chassis. Simple and fast installation.
Key Features at a Glance
- → Easy access for external system communication
- → Direct rear-mount installation on Controller Chassis
- → Two configurable RS422/485 ports (2 or 4 wire)
- → One RS422/485 2-wire connection
- → Fault/fail connections for Active and Standby Processors
- → Dedicated processor diagnostics connection
- → PSU shutdown monitor connections
- → IRIG-B122 and IRIG-B002 time sync option
- → MODBUS Master enable option on Trusted Communications Interface
Technical Structure
- ▪ Brand: Trusted (by ICS Triplex)
- ▪ Model: T8123
- ▪ Series: Trusted TMR
- ▪ Type: Processor Interface Adapter
- ▪ Mounting: Direct to Controller Chassis rear panel
- ▪ Communication ports:
- Port A: RS422/485 (2 or 4 wire, configurable)
- Port B: RS422/485 (2 or 4 wire, configurable)
- Port C: RS422/485 (2 wire fixed)
- ▪ Diagnostics connection: Dedicated processor link
- ▪ PSU shutdown monitor: Included connections
- ▪ Time sync options: IRIG-B122 / IRIG-B002 (field selectable)
- ▪ Protocol support: MODBUS Master (optional enable)
- ▪ Fault reporting: Active and Standby processor fail contacts
Installation Notes
- Power down the chassis before installation.
- Slide adapter into rear slot until firmly seated.
- Tighten retaining screws for secure hold.
- Connect RS422/485 wiring per your configuration.
- Use shielded cables for noisy environments.
Maintenance & Diagnostics
- LED status indicators on front edge for quick checks.
- Diagnostic port gives real-time health data.
- Hot-swap not allowed. Always power off to replace.
- Fault outputs help external systems log errors.
Compatibility
- Works with all Trusted TMR Controller Chassis.
- Supports MODBUS RTU master or slave modes.
- IRIG-B time code compatible with standard generators.
- RS422/485 signals match most PLC and SCADA systems.
Package Includes
- T8123 Trusted TMR Processor Interface Adapter
- Mounting screws and hardware kit
- Quick start guide
- Certificate of compliance
Warranty & Shipping
- 12-month warranty against manufacturing defects.
- Shipping carriers: FedEx, UPS, DHL with tracking.
- Express shipping available for urgent needs.
Typical Use Cases
- Connect a Trusted TMR system to a remote SCADA.
- Send processor fault alerts to a central control room.
- Sync multiple TMR chassis with IRIG-B time signal.
- Act as MODBUS master for field device polling.
- Monitor PSU shutdown for safety interlock logic.
Frequently Asked Questions (FAQ)
- Q1: Does T8123 support hot swapping?
A: No. Always power down the chassis before installing or removing this adapter. - Q2: Can I use both MODBUS master and IRIG-B at the same time?
A: Yes. MODBUS master is a software option and does not affect IRIG-B hardware connections. - Q3: What happens if the PSU shuts down?
A: The PSU monitor connection sends a signal to the adapter, which then reports it via the fault outputs. - Q4: How do I know if the adapter is working?
A: Check the diagnostic port with Trusted engineering software. Also look at onboard LEDs. - Q5: Is the 12-month warranty extendable?
A: Yes. Contact us for extended warranty plans and on-site support options.
Buyer Guidance & Experience Tips
- Order IRIG-B option if you need precise time sync across multiple chassis.
- Enable MODBUS master only when polling many slave devices.
- Keep spare T8123 in stock for critical TMR systems.
- Use FedEx Priority for urgent replacement. Use DHL Economy for lower cost.
- Always verify RS422/485 wiring before powering on to avoid damage.
- Label your fault/fail connections for easier troubleshooting later.
