Transmitter Isolato -MTL4644D | Dual Output Loop Power Supply

Description

MTL4644D Isolator: Power & Isolate 2-Wire Transmitters

The MTL4644D is a versatile isolator and power supply for 2-wire and 3-wire 4-20mA transmitters. It provides loop power, isolates the signal, and can drive two separate loads. It also supports HART digital communication for smart devices.

Technical Specifications

Brand & Model: MTL MTL4644D Transmitter Isolator
Input Signal: 0 to 24mA (from 2-wire transmitter)
Output Signal: 4 to 20mA (to two loads)
Transmitter Supply: 16.5V at 20mA
Load Capacity: Up to 450Ω at 20mA
Accuracy: Better than 15μA
Response Time: 50 microseconds
HART Support: Yes (on Channel 1 output)
Power Supply: 18-30V DC
Power Consumption: 96mA at 24V
Ripple: < 50μA peak-to-peak
Operating Temperature: -20°C to +60°C

Simple Setup

Connect your 2-wire transmitter to the input. Connect your controllers or recorders to the two outputs. The MTL4644D provides power to the transmitter and isolates the signal.

Frequently Asked Questions

• Q1: What is a 2-wire transmitter?
  A1: It is a device that uses the same two wires for both power and sending its 4-20mA signal.
• Q2: Can I use it with a 3-wire transmitter?
  A2: Yes, the MTL4644D works with both 2-wire and 3-wire transmitters.
• Q3: How many devices can it connect to?
  A3: It can drive two separate loads (like two controllers or indicators) with the same signal.
• Q4: Does it work with HART transmitters?
  A4: Yes, it allows HART digital signals to pass through for setup and diagnostics.
• Q5: What is the advantage of a fast response time?
  A5: A 50μs response means almost instant signal updating for critical process control.

Shipping & Package

Includes one MTL4644D unit. We ship globally using FedEx, UPS, and DHL.

Your Guarantee

This product comes with a 12-month warranty from the date of purchase.
