VE4002S2T1B1 KJ3209X1-BA1 Series I/O Termination Block for Automation Systems

Description

VE4002S2T1B1 KJ3209X1-BA1 12-Channel I/O Termination Block – Industrial Signal Interface

The VE4002S2T1B1 / KJ3209X1-BA1 (12P3905X012) termination block is designed for stable field wiring and reliable signal transfer in industrial automation systems.
It supports both analog and digital signals and helps simplify cabinet wiring while improving system stability.

 Key Advantages

• Stable signal termination
• Supports analog and digital signals
• Fast response improves control accuracy
• Compact DIN rail installation
• High electrical isolation protection
• Low maintenance design
• Industrial long-life operation

 Technical Overview

• Model: VE4002S2T1B1
• Assembly Number: KJ3209X1-BA1 / 12P3905X012
• Type: I/O Termination Block
• Voltage Compatibility: 115 / 230 VAC
• Channel Configuration: 8 Channels
• Signal Support: Analog & Digital
• Response Time: < 10 ms
• Isolation Voltage: 1500 V
• Mounting: DIN Rail
• Ingress Protection: IP20
• Operating Temperature: −20°C to +60°C
• Power Consumption: ≤ 12 W
• Material: Industrial-grade plastic
• Dimensions: 120 × 80 × 45 mm
• Weight: Approx. 500 g

Extended Technical Parameters

• Dielectric strength: ≥1500 VAC
• Contact resistance: ≤50 mΩ
• Wiring capacity: 0.5–2.5 mm²
• Recommended terminal torque: 0.5–0.6 Nm
• Shock resistance: 10 g
• Vibration range: 5–150 Hz
• Industrial EMC protection
• Expected service life: >10 years

Configuration Breakdown

VE4002S2T1B1
 ├─ Product Type
 │   └─ I/O Termination Block
 │
 ├─ Model Structure
 │   ├─ KJ3209X1
 │   │   └─ Base termination module
 │   ├─ BA1
 │   │   └─ Hardware revision
 │   └─ 12P3905X012
 │       └─ Manufacturing configuration code
 │
 ├─ Electrical Design
 │   ├─ Input Voltage: 115 / 230 VAC
 │   ├─ Isolation: 1500 V
 │   └─ Mixed signal interface
 │
 └─ Installation
     ├─ DIN rail mounting
     └─ Standard cabinet wiring

Product Selling Points

• Reduces wiring complexity
• Improves signal stability
• Suitable for retrofit systems
• Reliable under vibration conditions
• Compact design saves panel space
• Quick installation reduces labor time

Warranty

• 12 Months Warranty
• Fully tested before shipment
• Technical support included
