Description
Product Overview
The Woodward 8440-1935 belongs to the easYgen-3000 series. You may also know it as easYgen-3500-1-P1. This unit comes in a sheet metal chassis. Install it inside a cabinet for protection. Do not connect wires to the protective earth terminal on the controller. Use the bottom connector for protective earth if needed.
This controller includes an integrated generator group breaker control. Always short-circuit the current transformer before disconnecting the device. Failure to do so may cause severe injury or death.
Key Feature – Power Factor Explained
Power factor is the ratio of real power to apparent power. Three circuit types work with power factor:
Capacitive circuit
Purely resistive circuit
Inductive circuit
A resistive circuit has voltage and current waveforms in step. Its power factor is 1.00. We call this “unity.”
Technical Data (MECE Format)
Brand & Model
Brand: Woodward
Model number: 8440-1935
Alternate name: easYgen-3500-1-P1
Series: easYgen-3000 series
Accuracy & Resolution
Accuracy class: 0.5
Resolution: 16 bit
Current Setting Range
Setting range: 1 to 32,000 A
Inputs
Discrete inputs: isolated
Physical Dimensions
Front panel: 282W x 216H x 96D mm
Weight
Approx. 1,850 g
Chassis Type
Sheet metal chassis
Designed for cabinet mounting
Installation Guide
Mount the unit inside a cabinet
Do not use the protective earth terminal on the controller
Connect protective earth through the bottom connector only
Short-circuit the current transformer before removal
Follow all safety rules to avoid injury
Compatibility Note
This controller works with Modicon Quantum systems. For more details, visit Modicon Quantum products.
Warranty & Shipping
Warranty: 12 months from purchase date. Covers factory defects. Does not cover misuse or improper installation.
Shipping carriers: FedEx, UPS, DHL. Fast delivery worldwide.
Professional FAQ
Q1: What does accuracy class 0.5 mean?
A: The measurement error stays within 0.5% of the full scale value.
Q2: Why must I short-circuit the current transformer?
A: An open CT creates dangerous high voltage. This voltage can kill or cause severe burns.
Q3: Experience-based tip – What is the most common installation mistake?
A: People connect wires to the protective earth terminal on the controller. Use the bottom connector instead. This mistake happens often.
Q4: Experience-based tip – How do I check if my CT is shorted safely?
A: Use a shorting block or shorting bar. Verify with a multimeter before touching any wires.
Q5: Purchasing guide – New surplus or reconditioned?
A: New surplus suits critical sites like hospitals. Reconditioned works for backup units or training.
Selection Guide
Need high current measurement up to 32,000A? This model fits.
Need 0.5% accuracy? Choose this unit.
Installing inside a cabinet? This sheet metal chassis works well.
Using Modicon Quantum PLC? This unit connects easily.
Need a 12-month warranty? We provide it on all units.
