Description
Product Overview
HIMA X-AI3201 is an analog input module from the X-AI 32 01 series. It works with the HIMax programmable electronic system (PES). This module reads up to 32 analog signals. Use it for safety-critical applications up to SIL 3.
Key Benefits
- TÜV-certified for SIL 3 (IEC 61508, IEC 61511, IEC 62061)
- Also certified for Category 4 and PL e (EN ISO 13849-1)
- 32 analog inputs with common ground
- Each channel has its own transmitter supply (max 30 mA)
- Galvanic isolation from system bus and 24V supply
- Very fast 2 ms sampling time
Technical Specifications
- Brand: HIMA
- Model Number: X-AI3201 (X-AI 32 01)
- Series: HIMax
- Product Type: Analog Input Module
- Number of inputs: 32 channels
- Nominal range: 0/4 to 20 mA
- Operating range: 0 to 22.5 mA
- Digital resolution: 12-bit
- Shunt resistance: 200 Ω
- Weight: approx. 1.4 kg
Order Code – Tree Structure
- X = HIMax family
- AI = Analog Input
- 32 = 32 channels
- 01 = Version number
Power Supply Data
- Supply voltage: 24 V DC (-15% to +20%), SELV/PELV
- Current input (min): 500 mA (no channel load)
- Current input (max): 1.5 A (short-circuited transmitter supplies)
- Current per channel: 0 mA (no supply) to 30 mA (with supply)
Analog Input – Performance
- Digital resolution: 12-bit
- Sampling time: 2 ms
- Settling time (99%): 15 ms
- Measured value renewal: Matches user program cycle time
- Metrological accuracy (entire temp range): ±0.15% of final value
Protection & Isolation
- Common mode interference suppression: >60 dB at 50/60 Hz
- Withstand voltage per input: ≤10 V DC
- Max current via shunt: 50 mA (absolute max)
- Galvanic isolation: Yes, from system bus and 24V supply
Transmitter Supply – Key Features
- Number of supplies: 32 (one per channel)
- Output voltage: 26.5 V DC (+0% / -15%)
- Max output current per supply: 30 mA
- Undervoltage monitoring: 22.5 V DC
- Overvoltage monitoring: 30 V DC
- Max short-circuited supplies simultaneously: 12
- If more than 12 short for >3 seconds – all supplies turn off
- Auto-recovery within 30 seconds after overload clears
- Max load (transmitter + line): ≤750 Ω at 22.5 mA
Environmental & Mechanical
- Operating temperature: 0 to +60°C
- Storage temperature: -40 to +85°C
- Humidity: Max 95% relative, non-condensing
- Protection class: IP20
- Dimensions (H x W x D): 310 x 29.2 x 230 mm
Safety Certifications
- SIL: SIL 3 (IEC 61508, IEC 61511, IEC 62061)
- Category: Category 4 (EN ISO 13849)
- Performance Level: PL e (EN ISO 13849-1)
- Certification body: TÜV-certified
System Cable X-CA 005 (Companion Product)
- Connects X-CB 008 03/04 connector boards to field zone
- Use with field termination assemblies or inline terminals
- Cable type: LIYCY-TP 38 x 2 x 0.25 mm²
- Fine stranded wire for flexibility
- Outer diameter: approx. 16.8 mm (max 20 mm)
- Min bend radius – fixed: 5 x diameter
- Min bend radius – flexible: 10 x diameter
- Flame resistant and self-extinguishing (IEC 60332-1-2, -2-2)
- Available lengths: 5 to 30 meters
Installation Guide
- Insert module into any HIMax base plate slot
- Avoid slots reserved for system bus modules (see system manual HI 801 001 E)
- Use X-CA 005 system cable to connect to field devices
- Connect 24V DC SELV/PELV power supply
- Keep bending radius above minimum when routing cables
- Install in IP20 control cabinet only (not field-mounted)
Setup & Commissioning
- Module auto-detects when inserted in HIMax system
- Configure using HIMax engineering tool
- Set input range (0-20mA or 4-20mA) per channel
- Transmitter supply turns on automatically
- Monitor undervoltage/overvoltage flags in user program
- No external calibration needed
Diagnostics & Maintenance
- Module monitors each transmitter supply for short circuit
- Overload protection shuts down supplies if >12 channels shorted
- Auto-recovery after 30 seconds when fault clears
- LED indicators on module front (refer to HIMax manual)
- Check supply voltage regularly (24V ± tolerance)
- Keep ventilation clear – max operating temperature 60°C
Compatibility
- Fits all HIMax base plates except system bus slots
- Works with X-CB 008 03/04 connector boards
- Use with X-CA 005 system cable for field wiring
- Compatible with all HIMax CPUs and safety logic solvers
Packing List
- 1x HIMA X-AI3201 analog input module
- Documentation CD or manual reference card
- Original factory packing
- System cable and connector board sold separately
Warranty & Shipping
- 12-month factory warranty
- Fast delivery: FedEx, UPS, DHL
- Tracking number for all orders
Typical Applications & Diagnostic Ability
- Safety instrumented systems (SIS) for chemical plants
- Oil and gas emergency shutdown (ESD) systems
- Power plant turbine monitoring (4-20mA sensors)
- Burner management systems with analog feedback
- Diagnose short circuits and open circuits via supply monitoring
5 Professional FAQs
- Can I mix 0-20mA and 4-20mA sensors on the same module?
- Yes. Configure each channel independently in HIMax engineering tool.
- What happens if more than 12 transmitter supplies short circuit?
- All 32 transmitter supplies turn off after 3 seconds. System auto-recovers within 30 seconds after fault clears.
- Do I need external resistors for current measurement?
- No. Each channel has built-in 200Ω shunt resistor.
- Is this module hot-swappable in HIMax system?
- Refer to HIMax system manual. Some configurations support hot swap. Contact us for details.
- What is the maximum cable length for 4-20mA signals?
- Keep total load (transmitter + cable) ≤750Ω at 22.5mA. For 1.5 mm² copper, max length approx. 1000m.
Selection Guide – Pick the Right HIMax Analog Input Module
- Step 1 – Channel count needed: X-AI3201 gives 32 channels. For fewer channels, consider X-AI1601 (16 channels).
- Step 2 – Signal type: This module handles 0/4-20mA only. For voltage signals (0-10V), choose X-AV series.
- Step 3 – Need transmitter supply? X-AI3201 includes supplies. For external powered transmitters, choose X-AI3201 without supply option.
- Step 4 – Safety level required: This module is SIL 3 / PL e. For lower safety needs, SIL 2 modules cost less.
- Pro tip: For fast-changing signals (under 15ms), use the 2ms sampling time. For stable temperature signals, use filtering in user program.
